Open Journal of Marine Science, 2015, 5, 280-289
Published Online July 2015 in SciRes.
http://www.scirp.org/journal/ojms
http://dx.doi.org/10.4236/ojms.2015.53023
Environmental Factors and Seasonal
Variation in Density of Mussel Larvae
(Mytilus
edulis)
in Danish Waters
Hans Ulrik Riisgård
1*
, Kim Lundgreen
1
, Daniel Pleissner
2
Marine Biological Research Centre, University of Southern Denmark, Kerteminde, Denmark
Department of Bioengineering, Leibniz-Institute for Agricultural Engineering Potsdam-Bornim e. V., Potsdam,
Germany
*
Email:
[email protected]
2
1
Received 29 May 2015; accepted 13 July 2015; published 16 July 2015
Copyright © 2015 by authors and Scientific Research Publishing Inc.
This work is licensed under the Creative Commons Attribution International License (CC BY).
http://creativecommons.org/licenses/by/4.0/
Abstract
Mussel larval densities may fluctuate considerably on both small spatial and short temporal scales.
So far, only few and scattered data on the occurrence of mussel larvae have been reported from
Danish waters. However, seasonal variation in density of blue mussel (Mytilus
edulis)
larvae as re-
lated to environmental factors (temperature, salinity, phytoplankton biomass) is basic informa-
tion of relevance for future line-mussel farming in Danish waters. Here we report on the density of
mussel larvae in a number of potential farming sites in the inner Danish waters. The mussel larval
density measured in Skive Fjord, an eutrophicated inner branch of Limfjorden, during a period of
20 years, from 1989 to 2009, along with corresponding temperatures and chlorophyll
a,
makes up
the most important series of data reported here. In most years, a pronounced spring density peak
and a subsequently lower autumn peak could be seen in Skive Fjord, but most conspicuous in the
period 1993 to 2002 where the mean maximum spring larval density was 319 ± 260 ind∙l
−1
. Fur-
ther, data on mussel larval densities have been recorded on 4 locations in the Great Belt region:
Kerteminde Bay in 2008 to 2011, and in 2008 at 3 other locations: Musholm Bay, Svendborg Sund,
and Horsens Fjord. The maximum spring densities in the studied waters were observed in Skive
Fjord, typically in May, whereas 10 to 100 times lower peak densities were found at the other lo-
cations studied. The reported observations show that mussel larvae are omnipresent in the stud-
ied areas and it is suggested that the larval density is sufficient for recruitment to future line-
mussel farms.
Keywords
Mussel Larval Density, Seasonal Variation, Environmental Factors,
Mytilus edulis
*
Corresponding author.
How to cite this paper:
Riisgård, H.U., Lundgreen, K. and Pleissner, D. (2015) Environmental Factors and Seasonal Variation
in Density of Mussel Larvae (Mytilus
edulis)
in Danish Waters.
Open Journal of Marine Science,
5,
280-289.
http://dx.doi.org/10.4236/ojms.2015.53023
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
1. Introduction
H. U. Riisgård
et al.
The common blue mussel,
Mytilus edulis
L. may reproduce at any time of the year, but in the temperate zone
spawning is most frequent during spring and summer
[1].
Temperature seems to be the most important factor
that determines the annual reproductive cycle, and a cold winter tends to synchronize spawning the following
spring
[2]-[4].
The fertilized egg develops within 24 h to a trochophora larva that soon after secrets the first lar-
val shell to become a free swimming D-shaped veliger larva (100 to 120 µm shell length) feeding on small 2 to
4 µm particles
[5]-[9].
This stage lasts between 3 and 5 weeks
[10],
i.e.
time to reach ~300 µm, depending on
environmental factors (temperature, food ration, salinity) until metamorphosis when an extensible foot appears
and the larva becomes a pediveliger. The pediveliger larva seeks out different types of substrates in preparation
for settlement which involves a sequence of swimming and crawling behavior that culminates in attachment
once a suitable substrate is chosen. After settlement, morphological change (metamorphosis) results in a young
post-metamorphic mussel
[5] [9].
It is well known that mussel larval densities may fluctuate considerably on
both relatively small spatial (tens of metres) and short temporal scales (days) depending on the hydrography
[11],
but although information on density and dispersal of mussel larvae is crucial for understanding recruitment to
the adult wild stock and to aquaculture farm-ropes, only few and scattered data have up to now been reported
from Danish waters.
The Danish mussel production mainly comes from fishery on wild stocks of blue mussels in Limfjorden
which is a shallow-water system that connects with the North Sea to the west and Kattegat to the east (Figure
1).
The annual landings of blue mussels were about 100,000 tons in the 1990’s resulting in overfishing and a sub-
sequent reduction of the mussel stock, and in 2006-2008 the mussel fishery declined to about 30,000 tons per
year which led to restrictions and a national policy that aims at developing a sustainable production of cultured
mussels in balance with the extensive fishery of mussels
[12]-[14].
In recent years, the total annual Danish mus-
sel harvest has been around 35,000 tons, with 70% coming from Limfjorden. However, eutrophication and sea-
sonal oxygen depletion in Limfjorden cause high mortality of bottom-living wild mussels during late summer
[15],
and therefore, line-mussel farming has recently been introduced to increase the production of mussels and
to mitigate the habitat disturbance of mussel dredging
[16].
The aim of a recent mussel-research project (MarBioShell, 2008-2012) was to evaluate the potential of the
Great Belt region between the Kattegat and the Baltic Sea (Figure
1)
as a new line-mussel cultivation site to re-
duce the pressure on Limfjorden. Based on studies of actual growth of mussels in net-bags and on farm-ropes,
Riisgård
et al.
[16]
found that the growth rates in Great Belt compare quite well with the growth in Limfjorden
in spite of the lower salinity in Great Belt
[17]-[19],
and further, the deeper water and faster current speeds in
Great Belt are likely to prevent the eutrophication problems encountered in Limfjorden. The wild blue mussels
in the Great Belt have never been commercially exploited, but the MarBioShell studies showed that line-mussels
can grow from settlement in spring to more than 30 mm in shell length in November
[17].
However, to reach the
traditional consumer size of at least 45 mm takes about 18 months because of the winter period with weight loss
and subsequent re-growth during the next season, and therefore, Riisgård
et al.
[17]
suggested a new approach
of line farming of 30 mm “mini-mussels” during one growth season.
On this background, knowledge on seasonal variation in density of mussel larvae in Great Belt has become
important. Limfjorden and Great Belt have different levels of phytoplankton biomass (chlorophyll
a),
salinity
and current regimes, and therefore it has been of interest to compare the seasonal variation in density of mussel
larvae in Limfjorden with the abundance of mussel larvae in Great Belt and nearby waters as done in the present
study, where a 20 years long time series of mussel-larval data from Limfjorden is compared with new observa-
tions made on 4 locations in the Great Belt region. Such knowledge is of basic importance for understanding
time of mussel-larval settlement and amount of new recruitment to future mussel farms.
2. Material and Methods
2.1. Study Sites in Limfjorden and the Great Belt Region
Limfjorden connects the North Sea with the Kattegat, the mean water depth is about 5 m, and dominating wes-
terly winds cause a water exchange between the North Sea in west and Kattegat in the east (Figure
1),
and there
is a permanent horizontal salinity gradient, with 32 to 34 psu in the west and 19 to 25 psu in the east. Limfjorden
281
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
Figure 1.
Map of Denmark showing
Mytilus edulis
larval sampling sites in Limfjor-
den: (1) Skive Fjord, and in the Great Belt region: (2) Musholm Bay, (3) Svendborg
Sund, (4) Kerteminde Bay, (5) Horsens Fjord.
is eutrophic receiving nutrients from the catchment area which is dominated by agriculture
[15].
The water cur-
rent velocity 1 m above the bottom varies typically between <1 to 6 cm∙s
−1
, and the annual mean chlorophyll
a
concentration in the period 1982 to 2006 in the central northern part of Limfjorden (Løgstør Bredning) was 7.5 ±
12.1 µg∙l
−1
[18].
Data on mussel larval density in Skive Fjord, which is an inner branch of Limfjorden (Figure
1),
during the
period 1989 to 2009 were obtained from the Danish national monitoring program, Danish Nature Agency, Dan-
ish Ministry of Environment. According to the official monitoring guidelines (Miljøcenter Ringkøbing 2008), 20
l of water were sampled by means of a submersible pump (150 l∙min
−1
) resulting in equally sized subsamples
taken through the water column from bottom to surface by hauling the pump up with a speed of 0.5 m∙s
−1
. The
sampled water was filtered (60 µm mesh) to obtain a representative sample of the mussel larvae. Samples were
preserved in basic Lugol’s solution and examined in the laboratory by Orbicon A/S in order to determine the
concentration of mussel veliger larvae (and other zooplankton organisms).
Great Belt is one of the 3 Danish Straits (i.e. Little Belt, Great Belt, and The Sound), which form the transi-
tion between the high saline North Sea and the brackish Baltic Sea (Figure
1).
The water exchange between the
Baltic Sea and the open sea is driven both by the river run-off and by the meteorological conditions. The surface
salinity in the Great Belt is low, less than 20 psu whereas the salinity beneath the permanent halocline at about
15 m depth is high, about 30 to 34 psu. The current speed is usually about 50 cm∙s
−1
, and the annual mean chlo-
rophyll
a
concentration measured in the period 2000 to 2010 at 1 m depth in the northern Great Belt was 2.8 ±
2.4 µg∙l
−1
[17]-[19].
The present study reports on mussel larval density in the Great Belt region, including Horsens Fjord (Figure
1),
during the period 2008 to 2011. Water samples were collected at the 4 locations in 2008: Musholm Bay,
Svendborg Sund, Kerteminde Bay, and Horsens Fjord, and further in Kerteminde Bay in the period 2009 to
2011 by using a small conical zooplankton net (Ø24 cm, KC Denmark) with a mesh size of 80 µm and a 80 ml
282
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
collection cylinder. The plankton net was dropped to a known depth and then slowly hauled to the surface. The
sample was then transferred to a 100 ml bottle containing Lugol to conserve the mussel larvae. Before counting
in the laboratory using a reversed microscope (Leitz Labovert FS), the sample bottle was turned upside down
several times to ensure an even distribution of the mussel larvae. The total number of counted larvae was ex-
pressed as individuals per liter of filtrated water. The filtrated water volume (V) was calculated from the circular
area of the plankton net (A = 0.045 m
2
) and the length (L) of the vertical haul through the water column (V =
A
×
L)
which was dependent on the depth at the sampling location (2 to 6 m).
2.2. Environmental Data
Data on chlorophyll
a,
salinity and temperature in the Great Belt region and Skive Fjord were obtained from the
Danish national monitoring program, Danish Nature Agency, Danish Ministry of Environment. Temperature and
salinity were measured with a CTD at heights spaced 0.2 m apart, from 0.8 m below the surface down to about
0.3 m above the bottom. Chlorophyll
a
(chla) was determined from water samples taken from a depth of 1 m
and subsequently analysed at an authorized laboratory according to Danish national standards.
2.3. Statistical Analysis
One-way repeated measures analysis of variance (ANOVA) and Pearson product moment correlation (SigmaPlot,
version 12) were used to evaluate seasonal larval densities and temperature data, respectively. In all cases a sig-
nificance level of
α
= 0.05 was used.
3. Results
3.1. Larval Densities in Limfjorden and Great Belt Region
3.1.1. Limfjorden
The mussel larval density measured in Skive Fjord during a period of 20 years, from January 1989 to January
2009, along with corresponding temperatures and phytoplankton biomass expressed as chlorophyll
a
are shown
in
Figure 2
and
Figure 3.
In most years, a pronounced spring density peak and a subsequently lower autumn
75
65
T
C
(93)
(200, 120, 130)
T (°C), chl
a
(µg l
-1
)
55
45
35
25
15
5
-5
200
180
160
140
120
100
80
60
40
20
0
s
s
(s,787)
(s,511)
(s,283)
L (ind. l
-1
)
s
s
s
s
a
a
s
a
a
a
a
a
a
Figure 2.
Mytilus edulis.
Temperature (T, ˚C), chlorophyll
a
(C, µg∙l
−1
) (upper graph) and mussel larval
density (L, ind∙l
−1
) (lower graph) in Skive Fjord in the period 1989 to 1999. Spring (s) and autumn (a) peaks
are indicated. Values exceeding 75 µg chla∙l
−1
and 200 ind∙l
−1
are shown in brackets. Mean ± S.D. salinity in
the period was 24.3 ± 2.0 psu.
283
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
75
65
T (°C), chl
a
(µg l
-1
)
(110)
T
C
55
45
35
25
15
5
-5
150
120
s
(s, 712)
(s, 267)
a
a
s
s
a
s
a
s
a
a
s
a
s
L (ind. l
-1
)
90
60
30
0
Figure 3.
Mytilus edulis.
Temperature (T, ˚C), chlorophyll
a
(C, µg∙l
−1
) (upper graph) and mussel larval
density (L, ind∙l
−1
) (lower graph) in Skive Fjord in the period 2000 to 2009. Spring (s) and autumn (a)
peaks are indicated. Values exceeding 75 µg chla∙l
−1
and 150 ind∙l
−1
are shown in brackets. Mean ±
S.D. salinity in the period was 23.1 ± 2.1 psu.
peak can be seen. This trend, however, seems to be most conspicuous in the period 1993 to 2002 (with mean
maximum larval densities of 319.1 ± 260.0 ind∙l
−1
), and therefore the mean maximum spring and mean autumn
mussel larval densities for this period have been compared to previous (1989 to 1992, with 32.0 ± 30.3 ind∙l
−1
)
and subsequent (2003 to 2009, 56.7 ± 38.6 ind∙l
−1
) periods in
Table 1.
The few scattered data for the period
1989 to 1992 are not adequate for statistical tests, but statistical analysis showed that the spring density of mus-
sel larvae in the period 1993 to 2002 was significantly different (P
<
0.05) from the subsequent period 2003 to
2009 (F
(1,15)
= 7.528,
P
= 0.041). However, the difference in autumn larval density in the same two periods (46.2
± 35.6
versus
37.5 ± 35.8 ind∙l
−1
) was not significantly different (F
(1,15)
= 0.00249,
P
= 0.962). The mean annual
temperatures in Skive Fjord from 1982 to 2009 (Figure
4)
varied between 9.5 to 13˚C, and a statistical test
showed that there has been no significant increase in the mean annual temperatures (P = 0.452).
3.1.2. Great Belt
The densities of mussel larvae recorded in Kerteminde Bay in the period 2008 to 2011 are shown in
Figure 5,
and the date of maximum spring density of 3.4 to 7.9 ind∙l
−1
appears from
Table 2.
The larval density recorded
in Musholm Bay, Svendborg Sund and Horsens Fjord in 2008 are shown in
Figure 6
along with salinity, tem-
perature and chlorophyll
a,
and mean values of the latter in the sampling period are shown in
Table 3.
It is seen
that the maximum spring densities vary between 2.7 (Musholm Bay) and 12.4 larvae∙l
−1
(Svendborg Sund).
There is no statistical difference (P
=
0.586,
H
= 1.936 with 3 degrees of freedom) in mussel larval density be-
tween the 4 locations in the Great Belt region. However, due the limited number of measurements of larval den-
sity in Kerteminde Bay, only the period between July and October 2008 could be investigated for all locations.
4. Discussion
A pronounced spring peak in mussel larval density is typical for all locations studied, and the maximum spring
densities are found in Limfjorden (Figure
2
and
Figure 3, Table 1
and
Table 4)
whereas much lower peak den-
sities are found at the 4 locations in the Great Belt region. (Figure
5
and
Figure 6, Table 2
and
Table 3).
The
first yearly occurrence of mussel larvae, typically between mid-May and early June, appears to be closely re-
lated to the annual temperature cycle which apparently synchronize the spring spawning which seems to take
place when the water temperature has increased to about 12˚C, as reflected in the subsequent first appearance of
284
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
25
20
Temperature (°C)
15
10
5
0
Figure 4.
Annual mean (±S.D.) temperatures in Skive Fjord in the period 1982 to 2009.
28
26
24
22
20
18
16
14
12
10
8
6
4
2
0
-2
9
S
T
C
T (°C), S (psu), chl
a
(µg l
-1
)
L (ind. l
-1
)
8
7
6
5
4
3
2
1
0
Figure 5.
Mytilus edulis.
Salinity (S, psu), temperature (T, ˚C), chla (C, µg∙l
−1
), and mussel larval density (L,
ind∙l
−1
) in Kerteminde Bay in 2008 to 2011.
Table 1.
Mytilus edulis.
Mean ± S.D. maximum larval densities in Skive Fjord in spring and autumn in 3 periods between
1989 and 2009 along with corresponding water temperature, salinity and chlorophyll
a.
Years
1989-1992
1993-2002
2003-2009
1989-1992
1993-2002
2003-2009
Season
Spring
Spring
Spring
Autumn
Autumn
Autumn
Max. density (ind∙l
−1
)
32.0 ± 30.3
319.1 ± 260.0
56.7 ± 38.6
11.0
46.2 ± 35.6
37.5 ± 35.8
Temp. (˚C)
18.4 ± 3.6
13.8 ± 3.9
13.4 ± 3.4
14.3
15.3 ± 1.7
16.9 ± 1.7
Salinity (psu)
23.0 ± 2.6
22.0 ± 1.8
22.8 ± 1.6
25.9
24.7 ± 1.9
24.3 ± 1.5
Chla (µg∙l
−1
)
19.3 ± 2.5
17.9 ± 8.0
7.9 ± 6.5
17.0
31.8 ± 39.4
11.8 ± 11.5
285
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
Figure 6.
Mytilus edulis.
Salinity (S, psu), temperature (T, ˚C), chlorophyll
a
(C, µg∙l
−1
), and mussel larval
density (L, ind. l
−1
) in 2008 in (a) Musholm Bay; (b) Svendborg Sound; (c) Horsens Fjord.
Table 2.
Mytlilus edulis.
Maximum density of mussel larvae (peak) in Kerteminde Bay along with corresponding tempera-
ture, salinity and chlorophyll
a
measured at the peak date in the years 2008 to 2011.
Year
2008
2009
2010
2011
Date
17-July
22-June
16-July
18-May
Max. density (ind∙l
−1
)
3.4
4.6
3.9
7.9
Temp. (˚C)
16.8
14.1
20.1
10.9
Salinity (psu)
16.6
20.8
13.6
14.2
Chla (µg∙l
−1
)
1.7
0.9
2.4
1.6
Table 3.
Mytlilus edulis.
Maximum density of mussel larvae (peak) on 3 mussel larval sampling locations in 2008 along with
corresponding temperature, salinity and chlorophyll
a
measured at the peak date.
Location
Musholm Bay
Svendborg Sund
Horsens Fjord
Date
10-July
17-June
17-June
Max. density (ind∙l
−1
)
2.7
12.4
5.7
Temp. (˚C)
18.4
15.3
14.8
Salinity (psu)
12.9
15.8
20.4
Chla (µg∙l
−1
)
0.7
3.2
3.2
mussel larvae. After the maximum summer peak, mussel larvae may be found at low densities throughout the
season until a less pronounced secondary and shorter autumn peak may appear, as typically seen in Limfjorden
(Figure
2
and
Figure 3, Table 4),
but not in the Great Belt region (Figure
5
and
Figure 6).
In all cases, the
mussel larvae disappear when the autumn temperature has decreased below about 12˚C. This pattern reflects the
annual spawning cycle of mussels in temperate waters as described by Dare
[3].
The significant decrease in veliger larval density in Limfjorden after 2002 is not obvious. Statistical analysis
showed that the annual mean temperatures in Limfjorden (Skive Fjord) did not change significantly in the period
1982 to 2010 (Figure
4),
but the decrease in larval density may perhaps be correlated with overfishing (dredging)
and reduction of the mussel stock in Limfjorden
[12] [14],
or a tendency towards more severely reduced oxygen
concentrations and mass-killing of mussels during summer
[15].
Dolmer & Stenalt
[13]
measured the mussel larval densities from April to September 1999 at 2 locations in
Limfjorden, namely in the northern central part (Løgstør Bredning) and in Skive Fjord. At both locations the
286
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
Table 4.
Mytlilus edulis.
Maximum mussel larval density (L), water temperature (T), salinity (S) and chlorophyll
a
concen-
tration (C) on collection dates in Skive Fjord in the period 1989 to 2009. s/a = spring/autumn.
Year
1989
s/a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
s
a
Date
10-Jul
-
23-May
-
-
-
1-Jun
7-Sep
4-Jun
23-Aug
16-May
5-Sep
27-Jun
4-Sep
13-May
9-Sep
20-May
15-Sep
11-May
28-Sep
21-Jun
11-Oct
10-May
-
7-May
17-Sep
8-Apr
9-Sep
26-May
1-Sep
-
27-Sep
17-May
12-Sep
22-May
25-Sep
7-May
23-Jul
9-Jun
6-Jul
6-May
10-Aug
Max. L (ind∙l
−1
)
22
-
8
-
-
-
66
11
193
13
145
19
78
7
787
21
511
75
283
77
98
44
117
-
712
48
267
112
53
100
-
26
18
22
79
18
114
76
65
14
11
6
T (˚C)
20.6
-
14.2
-
-
-
20.4
14.3
15.1
15.0
15.1
16.1
20.0
16.1
9.3
16.2
13.5
14.3
12.5
14.3
15.8
12.5
18.4
-
10.4
14.3
7.6
18.5
13.1
16.9
-
13.6
12.0
16.8
12.6
16.6
11.0
17.7
20.2
20.1
11.7
20.5
20.9
23.0
23.8
23.1
4.8
3.7
2.1
3.5
26.2
24.2
25.5
23.8
25.1
11.0
5.9
5.7
7.7
13.0
19.4
23.2
20.4
21.6
21.3
22.9
10.0
15.0
8.1
34.0
19.0
34.0
20.2
25.9
24.6
27.6
21.3
24.9
21.4
23.7
21.7
25.3
23.4
26.8
24.6
25.5
23.2
23.4
20.3
22.0
17.0
15.0
2.0
34.0
49.0
27.0
9.0
17.0
13.0
18.0
130.0
17.0
20.0
22.0
14.0
11.0
25.3
17.0
S (psu)
23.5
C (µg∙l
−1
)
19
H. U. Riisgård
et al.
1990
1991
1992
1993
1994
1995
1996
1997
1998
1999
2000
2001
2002
2003
2004
2005
2006
2007
2008
2009
287
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
H. U. Riisgård
et al.
densities were below 20 larvae∙l
−1
until mid-April, when the densities begun to increase and subsequently peak
in mid-June with 579 larvae∙l
−1
and in May-June with 167 larvae∙l
−1
in Løgstør Bredning and Skive Fjord, re-
spectively. A small secondary peak was observed in Løgstør Bredning in August-September whereas no secon-
dary autumn peak was observed in Skive Fjord. The observations from Skive Fjord are not completely in agree-
ment with the observations for 1999 shown in
Figure 2,
where a distinct summer peak (with 98 larvae∙l
−1
,
Table
4)
and an autumn peak (44 larvae∙l
−1
) is seen. This underlines the importance of spatial and temporal variations
which in Limfjorden are mainly caused by a combination of wind- and density-driven water movements
[15].
Larsen
et al.
[20]
investigated the temporal patterns of bivalve larvae in the Isefjord, Denmark, and found that
the total concentration of bivalve larvae peaked in late June and early July, with one plankton sample having a
much higher concentration than the other samples with a density of 188 ind∙l
−1
. A small autumn peak with 7.8
ind∙l
−1
was observed in late August, and between these peaks the density ranged between 1.4 and 6.4 ind∙l
−1
. In
an earlier study in the Isefjord, Jørgensen
[4]
followed a cohort of bivalve larvae, mainly (about 90%)
Mytilus
edulis,
during its residence in the plankton. The initial mean density of 90 µm shell length larvae was 3150
ind∙l
−1
in late May, but this very high density must be considered as “an extreme peak situation in boreal neretic
waters”
[11],
and has not been report ever since. The abundance of mussel veliger larvae has also been studied
in the embayment of Knebel Vig, Denmark, by Fotel
et al.
[11]
who found that the larval density varied from
1.7 to 40.4 ind∙l
−1
in 1994 and 2.7 to 99.0 ind∙l
−1
in 1995. These observations along with the present account on
mussel larvae in Limfjorden and the Great Belt region show that mussel larvae are omnipresent in the inner
Danish waters, although the density may vary conspicuously between areas due to differences in number of
spawning mussels and hydrography. A recent study by Larsen
et al.
[21]
showed that even a low density of 2
larvae∙l
−1
in the vicinity of a suspended mussel-rope in Great Belt (Kerteminde Bay) resulted in 58 and 291 ju-
venile mussels cm
−1
after 16 and 27 d, respectively. Thus, the larval density in most Danish waters seems to be
sufficient for recruitment to many future line-mussel farms.
Acknowledgements
This work formed part of the MarBioShell project supported by the Danish Agency for Science, Technology and
Innovation for the period January 2008 to December 2012. Thanks are due to Sandrine Serre, Coralie Barth-
Jensen, and Caroline Vandt-Madsen for practical assistance, to the Danish Nature Agency, Danish Ministry of
the Environment, for providing zooplankton and hydrographical data.
References
[1]
[2]
[3]
[4]
[5]
[6]
Seed, R. (1976) Ecology. In: Bayne, B.L., Ed.,
Marine Mussels: Their Ecology and Physiology,
Cambridge University
Press, Cambridge, 13-65.
Savage, R.E. (1956) The Great Spatfall of Mussels in the River Conway Estuary in Spring 1940.
Fisheries Investiga-
tions Series II,
20,
1-21.
Dare, P.J. (1976) Settlement, Growth and Production of the Mussel,
Mytilus edulis
L., in Morecambe Bay, England.
Fisheries Investigations Series II,
28,
1-25.
Jørgensen, C.B. (1981) Mortality, Growth, and Grazing Impact of a Cohort of Bivalve Larvae,
Mytilus edulis
L.
Ophelia,
20,
185-192.
http://dx.doi.org/10.1080/00785236.1981.10426570
Bayne, B.L. (1965) Growth and the Delay of Metamorphosis of the Larvae of
Mytilus edulis. Ophelia,
2,
1-47.
http://dx.doi.org/10.1080/00785326.1965.10409596
Riisgård, H.U., Randløv, A. and Kristensen, P.S. (1980) Rates of Water Processing, Oxygen Consumption and Effi-
ciency of Particle Retention in Veligers and Young Post-Metamorphic
Mytilus edulis.
Ophelia,
19,
37-47.
http://dx.doi.org/10.1080/00785326.1980.10425505
Jespersen, H. and Olsen, K. (1982) Bioenergetics in Veliger Larvae of
Mytilus edulis
L.
Ophelia,
21,101-113.
http://dx.doi.org/10.1080/00785236.1982.10426580
Sprung, M. (1984) Physiological Energetics of Mussel Larvae (Mytilus
edulis).
I. Shell Growth and Biomass.
Marine
Ecology Progress Series,
17,
283-293.
http://dx.doi.org/10.3354/meps017283
Gosling, E. (2003) Bivalve Molluscs. Biology, Ecology and Culture. Fishing News Books, Blackwell, 443.
http://dx.doi.org/10.1002/9780470995532
[7]
[8]
[9]
[10] Thorson, G. (1961) Length of Pelagic Larval Life in Marine Bottom Invertebrates as Related to Larval Transport by
Ocean Currents. In: Sears, M., Ed.,
Oceanography,
American Association for the Advancement of Science, Washing-
288
L 111 - 2016-17 - Endeligt svar på spørgsmål 126: Spm., om ministeren vil fremsende de nævnte rapporter Miljømuslinger og muslinger som supplerende virkemidler fra 2013 og Combiopdræt 2015 samt artiklerne fra Aquaculture International 2014 og Open Journal, til miljø- fødevareministeren
ton DC,
67,
455-474.
H. U. Riisgård
et al.
[11] Fotel, F.L., Jensen, N.J., Wittrup, L. and Hansen, B.W. (1999)
In Situ
and Laboratory Growth by a Population of Blue
Mussel Larvae (Mytilus
edulis
L.) from a Danish Embayment, Knebel Vig.
Journal of Experimental Marine Biology
and Ecology,
233,
213-230.
http://dx.doi.org/10.1016/S0022-0981(98)00136-1
[12] Dolmer, P. and Frandsen, R.P. (2002) Evaluation of the Danish Mussel Fishery: Suggestions for an Ecosystem Man-
agement Approach.
Helgoland Marine Research,
56,
13-20.
http://dx.doi.org/10.1007/s10152-001-0095-6
[13] Dolmer, P. and Stenalt, E. (2010) The Impact of the Adult Blue Mussel (Mytilus
edulis)
Population on Settling of
Conspecific Larvae.
Aquaculture International,
18,
3-17.
http://dx.doi.org/10.1007/s10499-009-9266-2
[14] Dinesen, G.E., Timmermann, K., Roth, E., Markager, S., Ravn-Jonsen, L., Hjorth, M., Holmer, M. and Støttrup, J.G.
(2011) Mussel Production and Water Framework Directive Targets in the Limfjord, Denmark: An Integrated Assess-
ment for Use in System-Based Management.
Ecology and Society,
16,
26.
http://dx.doi.org/10.5751/ES-04259-160426
[15] Riisgård, H.U., Andersen, P. and Hoffmann, E. (2012) From Fish to Jellyfish in the Eutrophicated Limfjorden (Den-
mark).
Estuaries and Coasts,
35,
701-713.
http://dx.doi.org/10.1007/s12237-012-9480-4
[16] Petersen, J.K., Hasler, B., Timmermann, K., Nielsen, P., Tørring, D.B., Larsen, M.M. and Holmer, M. (2014) Mussels
as a Tool for Mitigation of Nutrients in the Marine Environment.
Marine Pollution Bulletin,
82,
137-143.
http://dx.doi.org/10.1016/j.marpolbul.2014.03.006
[17] Riisgård, H.U., Lundgreen, K. and Larsen, P.S. (2014) Potential for Production of “Mini-Mussels” in Great Belt
(Denmark) Evaluated on Basis of Actual Growth of Young Mussels
Mytilus edulis. Aquaculture International,
22,
859-885.
http://dx.doi.org/10.1007/s10499-013-9713-y
[18] Riisgård, H.U., Lundgreen, K. and Larsen, P.S. (2012) Field Data and Growth Model for Mussels
Mytilus edulis
in
Danish Waters.
Marine Biology Research,
8,
683-700.
http://dx.doi.org/10.1080/17451000.2012.678857
[19] Riisgård, H.U., Bøttiger, L. and Pleissner, D. (2012) Effect of Salinity on Growth of Mussels,
Mytilus edulis,
with Spe-
cial Reference to Great Belt (Denmark).
Open Journal of Marine Science,
2,
167-176.
http://dx.doi.org/10.4236/ojms.2012.24020
[20] Larsen, J.B., Frischer, M.E., Ockelmann, K.W., Rasmussen, L.J. and Hansen, B.W. (2007) Temporal Occurrence of
Planktotrophic Bivalve Larvae Identified Morphologically and by Single Step Nested Multiplex PCR.
Journal of
Plankton Research,
29,
423-436.
http://dx.doi.org/10.1093/plankt/fbm027
[21] Larsen, P.S., Lundgreen, K. and Riisgård, H.U. (2013) Bioenergetic Model Predictions of Actual Growth and Allome-
tric Transitions during Ontogeny of Juvenile Blue Mussels
Mytilus edulis.
In: Nowak, J. and Kozlowski, M., Eds.,
Mussels: Ecology, Life Habits and Control,
Nova Science, New York, 101-122.
289
