Udvalget for Fødevarer, Landbrug og Fiskeri 2013-14
FLF Alm.del
Offentligt

Agricultural

phosphorus

legislation

in Europe

F. Amery

ILVO

O.F. Schoumans

Alterra Wageningen UR

April 2014

PDF to HTML - Convert PDF files to HTML files

Agricultural

phosphorus

legislation

in Europe

ISBN: 9789040303531

April 2014

Limitation of liability:

This publication has been prepared by the editors

with the utmost care and accuracy. However, there is no guarantee about the

accuracy or completeness of the information in this publication. The user of this

publication renounces any complaint against the editors, of any kind, regarding

the use of the information made available through this publication. Under

no circumstances shall the editors be liable for any adverse consequences

arising from the use of the information made available through this publication.

Fien Amery

Oscar Schoumans

PDF to HTML - Convert PDF files to HTML files

Agricultural phosphorus

legislation in Europe

Fien Amery (ILVO)

Oscar Schoumans (Alterra Wageningen UR)

April 2014

PDF to HTML - Convert PDF files to HTML files

Amery, F. and O.F. Schoumans, 2014.

Agricultural phosphorus legislation in Europe.

Merelbeke, ILVO,

45 p.

This study has been conducted at the Institute for Agricultural and Fisheries Research (ILVO), Plant

Sciences Unit, Crop Husbandry and Environment Research Area (Belgium), and Alterra Wageningen

UR, and was partly funded by the Dutch Ministry of Economic Affairs (project BO-20-004-10).

PDF to HTML - Convert PDF files to HTML files

Preface

Phosphorus is gaining more and more attention because the limited availability of phosphorus

sources asks for resource efficiency and because phosphorus losses can result in eutrophication of

surface waters. One of the actions tackling these issues is the limitation of phosphorus fertilisation

on agricultural land. There is no European Directive or other regulation concerning phosphorus

application in agriculture. Nevertheless, some European countries and regions have legislation

restricting phosphorus fertilisation accommodated under several kinds of legislations (Nitrates

Directive, Water Framework Directive, etc.). However, this information is difficult to find and very

diverse. In this study, recent legislation concerning the restriction of phosphorus application on

agricultural land in Europe was gathered and compared. Experts in European countries/regions were

contacted in order to obtain the national and regional regulations regarding phosphorus fertilisation.

The information was controlled and inventoried. The different legislative systems, types of restricted

fertilisation, the extent of limits, etc. were compared. It was investigated whether the legislations

take the risk of phosphorus loss into account in the legislation.

The authors want to thank all contact and expert persons (see Table 1) for their time and efforts for

providing the correct information of national or regional legislation and for suggestions and

comments on the draft report.

The authors

PDF to HTML - Convert PDF files to HTML files PDF to HTML - Convert PDF files to HTML files

Contents

Summary

Introduction

Methods

Results

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

3.15

3.16

3.17

3.18

3.19

3.20

3.21

3.22

3.23

3.24

3.25

European legislation

Legislation in European countries and regions

Austria

Belgium: Flanders (northern region)

Belgium: Wallonia (southern region)

Czech Republic

Denmark

England and Wales

Estonia

Finland

France

Germany

Greece

Hungary

Ireland

Israel

Latvia

Luxembourg

Northern Ireland

Norway

Poland

Scotland

Spain

Sweden

The Netherlands

Discussion

4.1

4.2

General

Type of restricted phosphorus application

PDF to HTML - Convert PDF files to HTML files

4.3

4.4

4.5

4.6

Limits for different crops

Taking the phosphorus status of soils into account

Constraints for farmers

Additional legislation

References

Appendix 1: Questionnaire for COST action 869

Appendix 2: Questions for update of phosphorus legislation (2013-2014)

Appendix 3: Fertilisation prohibition periods

PDF to HTML - Convert PDF files to HTML files

Summary

Phosphorus (P) losses from agricultural fields can cause eutrophication and ecological deterioration

of surface waters. Although there is no general European Phosphorus Regulation or Directive, some

European Member States address the agricultural phosphorus losses via national or regional

legislation restricting the application of phosphorus. Most of this legislation concerns

implementations of the Nitrates Directive (91/676/EEC) in terms of National Action Plans, the Water

Framework Directive (2000/60/IEC) in terms of River Basin Management Plans and the Industrial

Emissions Directive (2010/75/EU). In 2014, we inventoried this phosphorus legislation in European

countries. Some of these countries (or regions) do not have direct phosphorus application

restrictions in addition to the chemical fertiliser N and manure N restrictions in the Nitrate

Vulnerable Zones. Other countries or regions have detailed, differentiated maximum phosphorus

application standards. The diversity in systems used, e.g. maximum application standards, balance

system, etc., complicates the comparison of international regulations. The regulations also restrict

different types of phosphorus fertiliser: all types, only manure, only chemical fertiliser, etc. Some

countries take only half of the phosphorus content in certain fertiliser types (compost and/or organic

fertilisers) into account. The crop phosphorus export depends upon the crop type; for this reason,

several countries and regions have crop type dependent maximum phosphorus application

standards. We have compared the maximum application rates for grassland, maize, cereals, potatoes

and sugar beets among Member States. Focusing phosphorus application restrictions on the high-risk

P areas is likely to be the most effective way to reduce agricultural phosphorus losses. A few Member

States do this by relating the maximum phosphorus application rates to the soil P status:

higher/lower limits for lower/higher soil P content. The success of this approach depends upon the

suitability of the soil P measurement method for estimation of P losses, and the extent of the

difference between the crop P export and the application limit. The hydrological conditions and

connectivity between the field and surface water are not taken into account, despite their value for a

real P risk approach. Phosphorus transfers to surface waters by erosion and surface runoff can be

restricted by installing a buffer zone where no fertilisation is allowed along waterways. The width of

the zone (0.5-500 m) and the type of fertilisation restricted varies widely among Member States. We

conclude that phosphorus legislation in European countries and regions varies from no direct

regulation to strict maximum phosphorus application rates that depend upon fertiliser type, crop

type, soil P content, etc. Minimising the P losses to surface waters will be facilitated if policymakers

use a more agro-environmentally sound approach for restricting P fertilisation.

PDF to HTML - Convert PDF files to HTML files

Introduction

The ecological status of surface waters has been improved over the last decades, but is still poor in

many European lakes and waterways (Figure 1) (Kristensen, 2012). High concentrations of

phosphorus (P), the limiting nutrient for algal growth in most inland surface waters, are especially

problematic. Due to the reduction in point sources (industry and waste water treatment plants)

agriculture is now often the main contributor to phosphorus losses to surface waters from rural areas

(Bogestrand et al., 2005). Phosphorus is a finite resource. The issue of increasing the efficient use of

phosphorus was recently tackled by the European Commission (Anon., 2013b) and others (Cordell et

al., 2009; Schröder et al., 2011). Phosphorus is an essential nutrient for crop production and is

therefore applied to the soil by chemical fertilisers, manure, compost, etc. Phosphorus can be lost

from the soil via erosion, surface runoff, subsurface runoff, leaching and tile drainage. To limit these

losses and to improve the ecological state of European surface waters, several mitigation options are

possible (Schoumans et al., 2014). One of the options is to limit the phosphorus application in

agriculture, but preferably without compromising crop yields. This can be done on a voluntary basis,

by following phosphorus fertilisation advice. However, recommendations for P fertilisation differ

more than threefold in Europe for similar soil-crop situations (Jordan-Meille et al., 2012). Another

option is to limit phosphorus fertilisation by law. In contrast to nitrate, there is no European Directive

or other regulation concerning phosphorus application in agriculture and P losses from agricultural

land. The Nitrates Directive (91/676/EEC) states that eutrophication due to agriculture should be

prevented, but phosphorus is not mentioned specifically in this Directive. Nevertheless, several

actions have been taken by European Member States by means of national legislation or voluntary

regional (agri-environmental) action plans. In the absence of a European legislative framework for

phosphorus, these national or regional phosphorus regulations can be accommodated under several

kinds of legislations (Nitrates Directive, Water Framework Directive, etc.; see section 3.1).

Information concerning phosphorus legislation is difficult to find and is often obsolete. The goal of

this study was to gather all recent legislation concerning the restriction of phosphorus application to

agricultural land in Europe and compare the different approaches used. The focus is limited to one of

the many mitigation options, namely legislation that restricts phosphorus fertilisation.

PDF to HTML - Convert PDF files to HTML files

Figure 1. Ecological water quality status in EU Member States (Anon., 2012b)

PDF to HTML - Convert PDF files to HTML files

Methods

In 2007, a

compilation of the phosphorus regulations in Europe

was performed as part of the EU-

COST action 869 “Mitigation options for nutrient reduction in surface water and groundwaters at the

river basin scale, in order to reach targets of the Water Framework Directive” and discussed with the

participants of the COST 869 Member States in Hamar (Norway). A questionnaire was made

(Appendix 1) and sent to the 27 Member States participating in COST action 869. By the end of 2013,

a large portion of the information received was obsolete and needed updating. Experts in the various

countries and regions were contacted in late 2013 or early 2014 to update this information using

either the same questionnaire or targeted and detailed questions (Appendix 2). Other experts were

contacted to edit and comment on the information gathered. The participating countries, regions,

contact persons and experts can be found in Table 1.

Table 1. Countries and regions participating, with their contact and expert person(s) (persons followed by *

have provided the information on the legislation of their country or region)

Country/Region

Austria

Belgium (Flanders)

Belgium (Wallonia)

Czech Republic

Denmark

England & Wales

Estonia

Finland

France

Germany

Greece

Hungary

Ireland

Israel

Latvia

Luxembourg

Northern Ireland

Norway

Poland

Scotland

Spain

Sweden

The Netherlands

Contact person(s)

Peter Strauss*

Fien Amery*, Georges Hofman

Charles Hendrickx*

Josef Hejzlar*

Line Block Hansen*, Hans Kjaer

Robert Willows*

Alvina Reihan*, Arvo Iital*

Kari Ylivainio*

Rémi Dupas*, Chantal Gascuel-Odoux

Thorsten Breitschuh*, Anja-Kristina Techen*, Bernhard Osterburg*

Yiannis Panagopoulos*

Peter Csatho*

Stan Lalor*, Karl Richards*

Moshe Shenker*

Viesturs Jansons*

Jeff Boonen*, Simone Marx*

Donnacha Doody*

Marianne Bechmann*

Leszek Hejduk*

Stephen Field*, Jannette MacDonald

Antonio Delgado*

Johannes Eskilsson*

Oscar Schoumans*, Maret Oomen

PDF to HTML - Convert PDF files to HTML files

3.1

3.1.1

Results

European legislation

General

Phosphorus legislation in European countries and regions is part of several Directives, legislations,

action plans, etc. European Directives are binding for each Member State; all of the stated objectives

must be met. National authorities have to adapt their laws and legislations to meet these goals, but

are free to decide in which way they want to achieve the goals. They can therefore take local human,

technical and physical settings into account. In contrast to European Directives, European

Regulations have a directly binding legal force in every Member State (Schoumans et al., 2011). Most

national or regional phosphorus legislation described below is part of the national or regional

implementation of EU Directives to reduce environmental pollution (Table 2). The most important

Directives relating to phosphorus are discussed in following sections. Member States can also take

actions in line with the Common Agricultural Policy (CAP) of the EU (section 3.1.4). Also conventions

can contribute to national or regional legislation. One of the aims of the OSPAR Convention

(Convention for the Protection of the Marine Environment of the North-East Atlantic) is to reduce the

nitrogen and phosphorus inputs by 50% compared to the 1985 input levels (Anon., 2008).

Table 2. European Directives in relation to phosphorus aspects

Bathing Water Directive

Directive on Dangerous Substances

Urban Waste Water Directive

Nitrates Directive

Water Framework Directive

Groundwater

Directive

(daughter

directive of Water Framework Directive)

Marine Strategy Framework Directive

Waste Framework Directive

Industrial Emissions Directive (replaces

IPPC Directive 96/61/EC)

76/160/EEC amended by 2006/7/EC

76/464/EEC = 2006/11/EC

91/271/EEC

91/676/EEC

2000/60/EC

2006/118/EC

2008/56/EC

2008/98/EC

2010/75/EU

3.1.2

Nitrates Directive

The Nitrates Directive (91/676/EEC) is an integral part of the Water Framework Directive (section

3.1.3). The mail goal of the Nitrates Directive is to protect water quality across Europe by preventing

nitrate pollution of ground and surface waters from agricultural sources and by promoting the use of

good farming practices. The Member States have to (1) identify polluted or threatened waters, (2)

designate Nitrate Vulnerable Zones (NVZs), (3) establish Codes of Good Agricultural Practice to be

implemented by farmers on a voluntary basis, (4) establish action programmes to be implemented by

farmers within NVZs on a compulsory basis and (5) monitor the progress of implementation,

reporting and (as needed) revision of NVZs and action programmes. Although phosphorus is not

mentioned in the Nitrates Directive, several implementations of the Nitrates Directive by Member

PDF to HTML - Convert PDF files to HTML files

States have included phosphorus regulations. As manure application in NVZs is restricted by the limit

of 170 kg N/ha/y (or higher N application standards in case of derogation), phosphorus application by

manure is indirectly limited by the Nitrates Directive in these areas. This is also the case for other

restrictions for manure in NVZs, e.g. regarding the manner of land application (not allowed when the

soil is water-saturated, flooded, frozen or snow-covered), restricted periods for application, etc.

3.1.3

Water Framework Directive

The aim of the Water Framework Directive (2000/60/EC, WFD) is to protect surface waters and

groundwater throughout the EU territory. Many water directives are part of this directive, e.g. the

Nitrates Directive, the Groundwater Directive, and others. The main environmental objectives are to

achieve and maintain a good status for all surface waters and ground waters by 2015, and to prevent

deterioration and ensure the conservation of high water quality where it still exists. In order to

achieve the objectives, River Basin Management Plans (RBMPs) have to be implemented. These plans

should provide a clear indication of the way the objectives set for the river basin are to be reached

within the required timescale. The first RBMPs were published in 2009; they are updated every six

years.

3.1.4

Common Agricultural Policy

The Common Agricultural Policy (CAP) is the agricultural policy of the European Union. It implements

a system of agricultural subsidies and other programmes. It was introduced in 1962 and has been

reformed several times. The 'Agenda 2000' reforms divided the CAP into two 'Pillars': production

support and rural development. The reform of 2003 has introduced the Single Payment Scheme (or

Single Farm Payment) in Pillar 1. Each country can choose if the payment is established at the farm

level or at the regional level. The farmers are obliged to keep their land in good agricultural and

environmental condition (cross-compliance). Farmers have to respect environmental, food safety,

phytosanitary and animal welfare standards. If farmers do not respect these standards, they pay a

penalty in the form of a lower farm payment. In Pillar 2, several rural development measures were

introduced including diversification, setting up producer groups and designating support for young

farmers. Agri-environmental schemes became compulsory for every Member State. Phosphorus

application restrictions can be part of Agri-Environmental Programmes (AEP).

3.2

Legislation

regions

European

countries

and

Legislation concerning phosphorus fertilisation is reported for every country/region listed below. The

legislation on phosphorus use in agriculture in European countries and regions varies widely. Some

countries have elaborate limitations on phosphorus application on agricultural land. Other countries

either do not have any phosphorus legislation or rely on voluntary measures as part of agri-

environmental programmes (CAP) or on the restrictions on the use of manure (Nitrates Directive) to

indirectly regulate the use of phosphorus. In this report, only direct regulations of phosphorus are

reported and discussed in detail. Sometimes respondents spontaneously provided additional

information regarding aspects of phosphorus regulations. This information was included in the report

if it was specific and relevant for phosphorus. It is possible that other countries or regions have

similar regulations, but that the respondents did not mention them.

PDF to HTML - Convert PDF files to HTML files

Some countries or regions have phosphorus application limits (also called ‘application standards’ or

‘maximum application rates’). The application limits can have a standard value, but can also be

differentiated in relation to the type of crop, the phosphorus status of the soil or even the crop yield.

Units for annual phosphorus applications are expressed in kg P/ha/y or kg P

/ha/y. Most

legislations concern all (acceptable) materials of phosphorus applications, but sometimes only

manure or only inorganic fertiliser are regulated. These differences should be taken in mind when

comparing various regulations (see 4.2).

3.3

Austria

Austria has no maximum phosphorus application rates or other P restrictions. Only indirect

regulations affect phosphorus application and losses, e.g. manure N restriction in the Nitrates

Directive, Good Agricultural Practices and erosion control.

3.4

3.4.1

Belgium: Flanders (northern region)

General

Every four years, a new Manure Decree comes into force in Flanders as an implementation of the

Nitrates Directive. The

current Manure Decree

(Anon., 2011) is valid in 2011-2014. This decree

addresses phosphorus and nitrogen application.

3.4.2

General limits

Maximum total phosphorus application standards are listed in the Manure Decree (Table 3). The

current application standards (2014) vary between 65 and 95 kg P

/ha/y. The limits depend on the

type of crop. Indicative limits for the next Manure Decree (2015-2018) are mentioned

(5−10 kg P

/ha/y lower than the standards of 2014). The maximum phosphorus application

standards are approximately 5 kg P

/ha/y smaller than the general phosphorus export by the crop,

resulting in a small negative phosphorus input into the soil. Phosphorus can be applied in the form of

manure, organic materials or chemical fertilisers (only derogation farms cannot use chemical P

fertilisers). Standard rates do not increase if more than one crop is cultivated in one year (standard

rate of the main crop is valid), with the exception of one cut of grass or rye followed by maize

(Table 3).

Table 3. Maximum total phosphorus application standards in Flanders (* limits for 2015-2018 are indicative)

Crop

Grassland (only mowing)

Grassland (not only mowing)

1 cut grass/rye + maize

Maize

Winter wheat - triticale

Other cereals

Other crops

Application limits (kg P

/ha/y)

2011-2012 2013-2014 2015-2016* 2017-2018*

PDF to HTML - Convert PDF files to HTML files

3.4.3

Deviations from the general limits

Only 40 kg P

/ha/y can be applied on soils located in phosphate saturated areas. These areas are

all areas that based on the study of Van Meirvenne et al. (2007) have a phosphate saturation degree

(PSD) (0-90 cm) equal to or larger than 35% with a probability of 95%. There is only a protocol for the

measurement of PSD in acid sandy soils (van der Zee et al., 1990a), which leaves a large part of

Flanders left out of PSD measurement. About 65 km² (1% of the agricultural land) is designated as

phosphate saturated area. Farmers in this area can be relieved of the strict application standard of 40

kg P

/ha/y if a soil analysis demonstrates a PSD smaller than 35%; in such a case the standard

application rates in Table 3 are valid. If the soil analysis demonstrates a phosphate binding capacity

(0.5*(Fe

+Al

)) equal to or smaller than 25 mmol P/kg soil (0-90 cm) and if the content of P

extracted by oxalate is equal to or smaller than 20 mmol P/kg soil (0-30 cm), then standard rates

(Table 3) minus 10 kg P

/ha/y are applicable.

No phosphorus can be applied on soils located in protection zone type 1 of water extraction areas for

drinking water. With the exception of direct excretion by two grazing livestock units per hectare, no

phosphorus can be applied on agricultural soils located in vulnerable nature areas (nature areas,

nature development areas, nature reserves and woods in the Flemish Region Plans) and on half-

natural and potentially important grassland soils located in woodlands.

The general phosphorus application limits are not valid for crops under permanent structures (such

as glasshouses and tunnel structures). The phosphorus dose for these soils is limited by the

fertilisation advice.

Only 50% of phosphorus that is applied by qualified compost (VLACO) has to be taken into account to

calculate the P application because compost has a substantial soil fraction.

3.4.4

Others

In Flanders, there are no subsidies for farmers that voluntarily apply less phosphorus than allowed by

law.

Part of the farm’s manure surplus must be processed or exported, but this is based on the nitrogen

production of manure and not on phosphorus.

3.5

Belgium: Wallonia (southern region)

There are no maximum phosphorus application rates or other P restrictions in the Walloon Region.

The only regulation affecting phosphorus application and losses is indirectly, e.g. by manure N

restriction in the Nitrates Directive, Good Agricultural Practices and erosion control.

PDF to HTML - Convert PDF files to HTML files

3.6

Czech Republic

There are no maximum phosphorus application limits or other P restrictions in the Czech Republic.

The regulations affecting phosphorus application and losses are indirect, e.g. by manure N restriction

in the Nitrates Directive, erosion control and buffer zone directives, and agri-environmental

programmes. In the latter, farmers can have a free soil P measurement (every 5 or 6 years, organised

by a state agency) and P fertilisation recommendation (not mandatory).

3.7

Denmark

Phosphorus from manure is indirectly restricted due to the limit of 140-170 kg N/ha/y for the entire

Danish territory. There are also

maximum application rates for total phosphorus,

but only an a

consultative basis (Anon., 2013d). A

tax on mineral phosphates for feed

(Anon., 2004a) was

introduced in 2005, which has generally resulted in reduced phosphorus excretion (Damgaard

Poulson, 2005; Damgaard Poulson, 2013). Phosphorus application by organic fertilisers consisting of

less than 75% manure (mainly sludge) is restricted to 30 kg P/ha/y over a period of 3 years and to a

maximum of 7 tonnes dry matter/ha/y (Anon., 2006a).

Animal farms that meet all three of the following criteria ( 1) wanting to expand or change their

production unit, 2) draining into Natura 2000 areas overloaded with P and 3) falling under P class 1, 2

or 3 (see bullets hereafter) have

additional restrictions

for the manure phosphorus surplus (Anon.,

2013a). This surplus is the phosphorus excretion of the farm animals (agreed table values or own

measurements) minus the phosphorus export by the crop (agreed table values) plus/minus

phosphorus in manure that is imported/exported (agreed table values, correction possible). Chemical

fertiliser is not included in the calculations. When the manure account is in balance, no further

restrictions are applied. If the surplus is positive, restrictions are applied, depending upon the soil

type and phosphorus status:



Class 0 (drained clay soils, Olsen-P < 4): no additional restrictions

Class 1 (drained clay soils, 4 < Olsen-P < 6): phosphorus surplus can increase at maximum by

4 kg P/ha/y

Class 2 (lowlands with Fe/P mole ratio < 20): phosphorus surplus is at maximum 2 kg P/ha/y

Class 3 (drained clay soils, Olsen-P > 6): no phosphorus surplus is allowed

3.8

England and Wales

England and Wales have no legislation concerning phosphorus application in agriculture. The only

regulation affecting phosphorus application and losses is indirectly, e.g. by manure N restriction in

the Nitrates Directive.

PDF to HTML - Convert PDF files to HTML files

3.9

Estonia

The

Water Act

(Anon., 2004b) determines how much phosphorus may be applied to agricultural

fields in Estonia. Farmers have to report fertiliser applications in a field book. The phosphorus

addition by manure is limited to 25 kg P/ha/y. Additional P can be applied by chemical fertilisers, but

this amount is restricted to the crop requirement (Table 4). These optimal (and maximum) rates for P

fertilisation for various crops, depending on the predicted yields, are defined in an attachment to the

Code of Good Agricultural Practice. The soil P should be accounted for by calculating the soil P

requirement coefficient, which depends on the Mehlich 3 P extraction concentration, the humus or

the organic C content and the soil texture (PMK, 2013).

Table 4. Requirements for P (kg P/ha/y) for different crops depending on the predicted yield and soil P

requirement coefficient.

Crop

Barley

Oats

Rape

Peas

Potatoes

Clover

Lucern

Maize

Predicted

yield

(tonnes/ha)

3.5

4.5

5.5

3.5

4.5

5.5

1.3

1.8

2.3

Soil P requirement coefficient

1.5

1.3

1.0

0.5

0.1

The soil P requirement coefficient depends upon the Mehlich 3 P extraction concentration, the humus or the

organic C content and the soil texture (PMK, 2013).

* Soil fertility is too low to assess the P requirements for this crop yield

The Water Act also limits the fertilisation timing and sets regulations for buffer zones (see Table 17).

No fertiliser use is allowed near karst springs and karst holes (10 m distance required, up to 50 m in

Nitrate Vulnerable Zones). Phosphorus regulation can also be found indirectly in the Water Act:

manure N restrictions and the maximum 1.5 livestock units per ha limit in Nitrate Vulnerable Zones.

PDF to HTML - Convert PDF files to HTML files

3.10 Finland

Finland has no legislation restricting phosphorus fertilisation. Phosphorus from manure is indirectly

restricted due to the limit of 170 kg N/ha/y for the entire Finnish territory. In addition, phosphorus

application is limited because 95% of Finnish farmers voluntarily join the Agri-Environmental

Programme (AEP).

This Programme sets the advised phosphorus doses

that may not be exceeded if

the farmer wishes to receive subsidies (Valkama et al., 2009). The doses depend on the crop type,

crop yield and the soil phosphorus status (Anon., 2007b). The soil phosphorus status is determined

by acid ammonium acetate extraction (pH 4.65); the fertility class also depends upon the soil texture

and the organic matter content (Ylivainio et al., 2014). The maximum P application rates in Table 5

are defined for basic yield levels. If yields are higher than 4 tonnes/ha for cereals, 3 tonnes/ha for rye

or 1.75 tonnes/ha for oil plants, maximum P application rates are linearly increased by 3 kg P/ha for a

yield increase of 25% (up to 6 kg P/ha, only for soil P classes where P application is allowed).

More total P can be applied by organic fertilisers than by chemical fertiliser as only 85% of P in

manure (40% in manure of fur-animals, i.e. foxes, minks, finnraccoons and fitchets) and 40% of P in

sludge is considered to be plant available in the current AEP. In the next AEP (from 2015 on) this will

probably be increased to 100% for manures, and 60% for fur-animal manures and sludge.

Table 5. Advised phosphorus application rates (kg P/ha/y), to be followed under the Finnish Agri-Environmental

Programme (Anon., 2007b). The advised rates are increased for higher than basic yields (see text).

Crop

Cereals

Potato

Sugar beet

Grassland

Poor

28-34

32-40

Soil P status

Sufficient

8-14

8-24

High

0-20

0-14

The soil P status depends upon the P concentration in the acid ammoniumacetate extract, the soil texture and

the organic matter content (Ylivainio et al., 2014).

3.11 France

ministerial decree

(Anon., 2012a), the French implementation of the IPPC Directive (now IED), sets

that the phosphorus fertilisation has to be in equilibrium with the crop export from the field and that

the absorption capacity of the soils must not be exceeded. This legislation concerns “Installations

Classées pour la Protection de l’Environnement”

(ICPE). This applies to the largest farms, those with

>100 dairy cows, >450 pigs or >30000 poultry. These ICPE farms have to prove compliance with the

phosphorus equilibrium requirement by an impact study when setting up a new farm or expanding

an existing one. There is no practical implementation on paper in which way the phosphate sorption

capacity should be taken into account and how the administration should evaluate these impact

studies. Similar to the Nitrates Directive, practical implementation of the ministerial decree falls

under the responsibility of the local authorities (department or region). However, national guidelines

exist to estimate the phosphorus balance: several ministerial circulars (15/05/2003, 19/08/2004,

07/09/2007) set animal excretion coefficients and crop P contents. The methodology to estimate

crop yield is specified by local expert groups in each region, as part of the Nitrates Directive action

programme. In conclusion, the implementation of this national decree varies strongly across France.

PDF to HTML - Convert PDF files to HTML files

In this section, region of Brittany is taken as an example because the severe impacts of nutrient

pollution from agricultural origin has forced the authorities to take action; this explains why

phosphorus legislation is more advanced there than in other regions. The

Loire-Brittany River Basin

Management Plan

(RBMP) (Anon., 2009d), developed and published according to the Water

Framework Directive, re-emphasises the objective of reducing phosphorus transfer from agricultural

diffuse sources. Particularly, the Loire-Brittany RBMP delineates 14 priority catchments, where

balanced fertilisation must be achieved under the responsibility of the local prefect. Hence, local

authorities must comply with both the IPPC/IE ministerial decree and the RBMP when deciding to

authorise an ICPE farm. Administrative controls differ depending on the farm size, farm type and

whether or not it is located in an RBMP priority catchment.



Large (production >25000 kg N) or new farms must show a soil phosphorus balance

(tolerance of 10% larger phosphorus input compared to phosphorus export). The phosphorus

export is calculated by the crop yield and crop phosphorus content (the latter can be found

in the agreed tables in Anon. (2009c)). There are no regulations under the ministerial IE

decree regarding the way crop yields have to be measured (see above). According to the

Nitrates Directive implementation in Brittany, the reference crop yield is the average of the

three lowest yields over the past five years.

Smaller farms (< 25000 kg N) and farms that are not new have maximum phosphorus

application standards depending on the farm type (poultry or not) and whether or not it is

located in a priority catchment (Table 6).



The limits are defined on a farm scale, not on a plot scale basis.

Table 6. Phosphorus application limits for small farms (< 25000 kg N) and farms that are not new in Brittany, in

kg P

/ha/y.

Priority water basis

Non-priority water basin

Poultry

Non-poultry

Moulin Neuf, Kerne Uhel, Etang au Duc, Guerledan, Gouet, L’Arguenon, Rophemel, La Valière, Villaumur, La

Chapelle Erbrée

In the French department Maine-et-Loire, the phosphorus fertilisation is regulated by a

departmental

decree

(Anon., 2009a), which is the implementation of the Nitrates Directive. This is a local initiative,

because P problems had been identified in this department. The phosphorus fertilisation (by

chemical fertiliser, sludge and manure) is restricted to 100 kg P

/ha/y (farm basis, no control on

field scale). If it is not possible to apply less than 100 kg P

/ha/y, mandatory farm-specific

measures should be taken to limit the transfer of phosphorus before the end of the Action

Programme. These measures are based on a farm diagnosis made by an expert from the “Chambre

d’Agriculture”

and can include buffer strips, hedgerows, etc. A soil phosphorus analysis is mandatory

in the current action programme (6 years) but the result has no practical implications. The 5

French

implementation of the Nitrates Directive is expected in mid-2014. Because the new action

programmes will be set at the regional level instead of at the department level, the departmental

legislation of Maine-et-Loire will not be in force anymore and will not be included in the Pays de la

Loire regional legislation.

PDF to HTML - Convert PDF files to HTML files

3.12 Germany

In Germany, fertilisation of agricultural soils in regulated by the

Fertilisation Ordinance

(Düngeverordnung)

(Anon., 2007a), the implementation of the Nitrates Directive (whole territory

approach). Because the phosphorus fertilisation must correspond to the crop and soil needs (Anon.,

2009b), the soil phosphorus concentration has to be determined at least every six years according to

the Fertilisation Ordinance. Phosphorus fertilisation is not restricted by fixed application limits, but

rather by a soil balance system. The soil phosphorus balance (soil P input minus output) must not

exceed 20 kg P

/ha/y as a six-year average. All types of phosphorus inputs have to be taken into

account. The phosphorus output can be calculated by official phosphorus contents of crops and the

crop yield. The crop yield can be determined by weighing or estimation (forage crops, control the

year after by a stable balance). These calculations do not have to be registered but must be available

for auditing by the authorities. Since these regulations are poorly defined and verification of the

calculated values has proven to be difficult, Ekardt et al. (2011) have questioned their effectiveness.

This balance system offers flexibility to the farmer, because there is no yearly limit, the system takes

crop yields and multiple crops during one entire year into account.

In addition to the balance limit of 20 kg P

/ha/y, the “soil need” (based on fertilisation advice) can

be applied to soils with a phosphorus content below 20 mg P

/100 g, measured by calcium acetate

lactate extraction. This soil P content corresponds to the upper limit of the target soil P concentration

class, according to the

German soil P fertility classes

(Kerschberger et al., 1997).

In some federal states there are optional support programmes with the aim to reduce the risk of soil

erosion or to establish buffer strips next to water bodies.

3.13 Greece

Greece has no maximum phosphorus application rates or other P restrictions. The only regulation

affecting phosphorus application and losses is indirectly, e.g. by fertiliser N restrictions in the Nitrates

Directive.

3.14 Hungary

Hungary has no maximum phosphorus application rates or other P restrictions. The only regulation

affecting phosphorus application and losses is indirectly, e.g. by manure N restriction in the Nitrates

Directive and Good Agricultural Practices in agri-environmental programmes.

3.15 Ireland

3.15.1 General

Every four years, a new Irish fertilisation legislation comes into force as an implementation of the

Nitrates Directive. The current legislation (Anon., 2014a) is valid during 2014-2017.

PDF to HTML - Convert PDF files to HTML files

3.15.2 General application limits

The phosphorus application limits depend on the soil phosphorus status and the crop type (Table 7

and 8). The larger the soil P content, the lower the limits. The result of the Morgan’s test (extraction

with sodium acetate at pH 4.8) classifies a soil into index 1 (low), 2, 3 or 4 (high) (Table 7 and 8). The

soil analysis is not mandatory, except for derogation farms. When no soil analysis is available, index 3

is assumed. Tests older than 5 years are not valid, except when the results indicate index 4. Fields

used for more than one crop in a year are permitted to receive the combined maximum available P

application of the two crops being grown.

Both P applications by chemical fertiliser and organic fertilisers are considered, but only 50% of P in

organic fertilisers is considered for P application calculations for soils of index 1 or 2. The P contained

in concentrate feeds fed on the farm at rates greater than 300 kg of feed per 85 kg of organic N

excreted is also included as a source of available P fertiliser.

Table 7. Maximum P application standards (kg P/ha/y) for grassland in Ireland depending on the soil P index

(Morgan’s test)

0-3.0 mg P/l

General

Grassland stocking rate

(kg/ha/y)

≤ 85

86-130

131-170

170-210

>211

Cut only

First cut

Subsequent cuts

P index (Morgan’s test)

3.1-5.0 mg P/l 5.1-8.0 mg P/l

> 8.0 mg P/l

Total annual N (kg) excreted by grazing livestock averaged over the eligible grassland area.

Grassland with no grazing livestock on the holding or areas of farms where hay or silage is produced for sale

off the holding on farms stocked <85 kg grassland stocking rate.

An additional 15 kg P/ha may be applied on soils at P index 1, 2 or 3 for each hectare of pasture establishment

taken.

Manure produced by grazing livestock on a holding may be applied to index 4 soils on that holding in a

situation where there is a surplus of such manure remaining after the phosphorus fertilisation needs of all

crops on soils at P index 1, 2 or 3 on the holding have been met by the use of such manure produced on the

holding.

The maximum P fertilisation of grassland shall not exceed that specified for stocking rates less than or equal

to 170 kg/ha/y unless a minimum of 5% of the eligible area of the holding is used to grow crops other than

grass or a derogation applies in respect to the holding.

PDF to HTML - Convert PDF files to HTML files

3.15.3 Deviations from the general limits

In addition to the maximum P application standards, 5 (2013-2014), 3 (2015-2016) or 0 (2017 and

later) kg P/ha/y can be applied if this additional fertilisation dose is given by spent mushroom

compost or by manure produced by pigs or poultry (from holdings without increase in the scale of

the production since 1 August 2006).

Where proof of higher yields of cereals is available, an additional 3.8 kg P/ha may be applied on soils

at P index 1, 2 or 3 for each additional tonne above a yield of 6.5 tonnes/ha. The higher yields shall

be based on the best yield achieved in any of the three previous harvests, at 20% moisture content.

The fertilisation rates for soils which have more than 20% organic matter shall not exceed the

amounts permitted for index 3 soils.

Table 8. Maximum P application standards (kg P/ha/y) for arable crops in Ireland depending on the soil P index

(Morgan’s test) and the crop type

Crop

Cereals

Sugar and fodder beet

Potatoes (main crop)

Potatoes (early)

Potatoes (seed)

Maize

Field peas

Field beans

Oilseed rape

Linseed

Swedes/Turnips

Kale

Forage rape

Asparagus (establishment)

Asparagus (maintenance)

Celery

Swede

Other vegetables

Apples (desert)

Apples (culinary)

Pears,

cherries,

plums,

strawberries

Berries

0-3.0 mg P/l

125

P-index (Morgan’s test)

3.1-6.0 mg P/l 6.1-10.0 mg P/l

100

115

100

115

100

> 10.0 mg P/l

At pH ≥7: 20 kg P/ha/y can be applied on soils with P index 4.

Must be incorporated prior to or during sowing

PDF to HTML - Convert PDF files to HTML files

3.15.4 Other

In addition to the requirements regarding the manner of land application by the Nitrates Directive

(no application allowed when the soil is water-saturated, flooded, frozen or snow-covered), the Irish

implementation mentions other restrictions: no organic or chemical fertiliser nor soiled water can be

applied when heavy rain is forecast within 48 hours (the Met Eireann weather forecast must be

consulted) or when the ground slopes steeply (>20% for grassland, >15% for other land) and there is

a risk of water pollution (having regard to factors such as surface runoff pathways, the presence of

land drains, the absence of hedgerows to mitigate surface flow, soil condition and ground cover).

3.16 Israel

Israel has no maximum phosphorus application rates. However, new regulations (approved by 2011)

restrict total P concentration in treated wastewater used for irrigation to 5 mg/L (1 mg/L if released

to the environment). The new limits are gradually enforced and have large impacts given the

widespread use of treated wastewater for irrigation (50% of total irrigation). There is also an indirect

P application limitation due to the limitation for biosolids to the N crop demand.

3.17 Latvia

Latvia has no general maximum phosphorus application rates or other P restrictions. Waste water

treatment plant (WWTP) sludge application is limited to 40 kg P/ha/y (or by heavy metal

concentration or NH

concentration).

3.18 Luxembourg

In Luxembourg there is no direct legislation restricting phosphorus fertilisation. The manure P

application is indirectly restricted by the manure N limit in the Nitrates Directive. In addition,

phosphorus application by other fertilisers is also limited because 85% of farmers with 95% of

agricultural land voluntarily join the programme of the

Landscape Premium

(Agri-Environmental

Programme) (Anon., 2014b). In this program, maximum P application rates are defined for the

parcels under this program (Table 9). The limits depend upon the crop type, the yield and the P

fertility class. The latter is measured by the CAL-method (calcium acetate lactate) and varies between

regions (Table 10). The limits are defined for a certain yield and are lowered or increased if the yield

is lower or higher, respectively. The limits are only valid in case of application of mineral fertiliser,

compost, sludge or the combination of mineral and any organic fertiliser (also manure). Application

of manure alone is not limited by these application standards. Compliance is set on a 5 years basis

(Landscape Premium period): the sum of P application during the 5 years is limited to the sum of the

5 yearly limits. In the ‘very high’ fertility class only solid manure and slurry (no compost, no sludge,

no mineral P fertiliser) are allowed, and above 40 mg P

/100 g soil only grazing is allowed.

PDF to HTML - Convert PDF files to HTML files

Table 9. Maximum P application rates (kg P

/ha/y) under the Landscape Premium programme in Luxembourg

for a standard crop yield (in tonnes of dry matter/ha/y, except for potatoes (fresh matter))

P fertility class

Crop

Cereals (50 t DM/ha)

Maize (15 t DM/ha)

Potatoes (35 t FM/ha)

Grassland (80 t DM/ha)

Very low

120−125

180−186

162

100−148

Low

90−95

150−156

132

70-118

Target

60−65

120−126

102

40−88

High

30−33

60−63

20−44

Very high

See Table 10

Table 10. Ranges for P fertility classes in Luxembourg (mg P

/100 g dry soil measured by the CAL-method)

P fertility class

Region

Gutland

Ösling (stony soils)

Very low

0−5

0−7

Low

6−11

8−14

Target

12−20

15−23

High

21−30

24−35

Very high

≥31

≥36

3.19 Northern Ireland

The application of

chemical

phosphorus fertiliser is restricted by the

Northern Irish Phosphorus (Use

in Agriculture) Regulations

(Anon., 2006b). Fertilisation is only allowed if the farmer can show that

the applied amount is not above the crop requirement as determined by the RB209 fertiliser manual

(Anon., 2010a). This crop requirement depends on the soil phosphorus status, determined every four

years using the Olsen method (Table 11). The target soil P index is index 2 (Olsen P 16-25 mg/l) and

index 3 for vegetables (Olsen P 26-45 mg/l). Advised phosphorus application rates are

0−125 kg P

/ha/y for winter wheat, 0−150 kg P

/ha/y for grass and 0−250 kg P

/ha/y for

potatoes (Table 11). Advised application rates are higher/lower if the yield is higher/lower than the

table values, except for potatoes. The correction for the yield is the P quantity additionally or not

extracted compared to the standard yield, calculated by agreed table values (Anon., 2010a).

These application rates are also valid for a combination of chemical P fertiliser and other P

applications (manure, organic fertilisers, etc.). The application of non-chemical fertiliser itself is not

regulated, i.e. there are no restrictions if no chemical P is applied except for indirect restrictions

resulting from the 170 kg N/ha/y limit implemented through the Nitrates Directive. Because crop

needs are taken into account, phosphorus limits will be higher when two crops are grown in one

year.

Derogation farms as defined by the implementation of the Nitrates Directive are restricted to a farm

P surplus of 10 kg P/ha/y (Anon., 2010b).

In addition to the guidelines on land application of fertilisers under the Nitrates Directive (no

application allowed when the soil is water-saturated, flooded, frozen or snow-covered), the

Phosphorus Regulations set out additional restrictions: no chemical P fertiliser may be applied when

PDF to HTML - Convert PDF files to HTML files

heavy rain is forecast within 48 hours (Northern Ireland Met Office forecast), on steeply sloping

(>20%) ground where a significant risk of causing water pollution is determined after evaluating

factors such as proximity to waterways, soil condition, ground cover and rainfall. Chemical fertiliser

shall not be applied to any land in a location or manner which would make it likely that chemical

fertiliser will directly enter a waterway or groundwater, or within 1.5 meters of any waterway.

Table 11. Soil P index categories and corresponding fertilisation rate for different crops in Northern Ireland

(Anon., 2010a)

Soil P index

Soil P (Olsen P, mg/l)

Crop

Grass (establishment)

Grass (grazed)

Grass (silage)

Winter barley, winter wheat (8 t/ha)

Spring wheat, spring barley, rye,

triticale, oats (6 t/ha)

Winter oilseed rape (3.5 t/ha)

Spring oilseed rape (2 t/ha) or linseed

(1.5 t/ha)

Peas (4 t/ha) and beans (3.5 t/ha)

Potatoes (50 t/ha)

Sugar beet (60 t/ha)

Forage maize (40 t/ha fresh)

Forage swedes and turnips (65 t/ha)

Forage rape and stubble turnips (grazed)

Fodder beet and mangels (65 t/ha

Kale (40 t/ha cut)

Forage rye and forage triticale (20 t/ha)

Ryegrass seed

0−9

120

150

120

105

110

100

250

110

115

105

110

10−15

16−25

26−45

Fertilisation rate (kg P

/ha/y)

120

210

170

100

>45

Fertilisation rate is 5 kg P

/ha/y (10 P

/ha/y for oats) higher for P index 0, 1 and 2 if straw is removed

3.20 Norway

There are no maximum phosphorus application rates in Norway. However, livestock density is limited

to maximum 2.5 livestock units per ha. Since the maximum livestock units are based on P content in

excretion, this limitation corresponds to a limit of approximately 35 kg P/ha. Because this is only a

restriction on farm basis, the phosphorus application on one parcel can be substantially higher or

lower than 35 kg P/ha. Farmers, in small areas near highly polluted lakes, can get subsidies when

they apply P fertiliser doses below national recommended levels, depending on crop type and soil P

status.

There are also more indirect regulations of phosphorus, such as a 2 m buffer zone alongside surface

waters. Subsidies are available to farmers who implement strategies that indirectly affect

phosphorus (i.e. no tillage in autumn, grassy buffer zones along surface waters, sedimentation

ponds, grass cover in landscape depressions and establishing a nutrient management plan).

PDF to HTML - Convert PDF files to HTML files

3.21 Poland

Poland has no maximum phosphorus application rates or other P restrictions.

3.22 Scotland

A general binding rule in the

Water Environment Regulations

(Anon., 2013c) requires that fertilisers

must not be applied to land in excess of the nutrient needs of the crop. This pre-authorised

requirement allows farmers the flexibility in deciding the best method of compliance with the rule

depending on their circumstances and will only be investigated where a breach of the rule is

detected. There is no reporting system nor mandatory soil analysis. The regulations also require

buffer zones to be maintained (see Table 17 below).

3.23 Spain

Spain has no general maximum phosphorus application limits or other P restrictions. The regulations

affecting phosphorus application and losses are all indirect, e.g. by manure N restriction in the

Nitrates Directive and erosion control in agro-environmental programmes. Only in the region of

Extremadura, the phosphorus fertilisation for olive, rice, tobacco and deciduous fruit trees is limited

to 80 kg P

/ha/y. Larger rates can be applied under special circumstances. A soil analysis is

required every five years in this case as a basis for fertilisation and amendments.

3.24 Sweden

Livestock manure or other organic fertilisers may not be applied in quantities above 22 kg P/ha/y,

calculated as an average for the holding's entire application area per year during the last 5 years. This

regulation does not limit the application for a specific field but rather for the entire farm. The farmer

can use standard values for P content of the manure, or calculate the P content by making a feed

balance. Farmers with more than 400 animal units (as

defined by the European Commission)

or other

facilities which fall under the Industrial Emissions Directive (2010/75/EU) can have additional specific

obligations formulated in their permissions. Since the farmer has to account for the phosphorus

situation in the field, stricter phosphorus standards are possible for a specific farm with high soil

phosphorus contents. Sweden has no limits for chemical P fertilisation.

3.25 The Netherlands

3.25.1 General

Every four years in the Netherlands, a new fertilisation legislation comes into force as an

implementation of the Nitrates Directive. The 5

Dutch Action Plan of the Nitrates Directive will

probably accepted by the end of April 2014 and implemented in the current ‘Meststoffenwet’ (Anon.,

2014c) and the ‘Uitvoeringsregeling

Meststoffenwet’

(Anon., 2014d). Phosphorus and nitrogen

application are both addressed in this legislation.

PDF to HTML - Convert PDF files to HTML files

3.25.2 General application limits

The maximum phosphorus application standards are different for grassland (85-120 kg P

/ha/y)

and for arable land (55-120 kg P

/ha/y). The crop cultivated at the start of the calendar year (15

of May) determines which set of maximum application standards should be used. Phosphorus can be

given by manure, organic materials or chemical fertilisers. The maximum application standard

depends upon the phosphorus status of the soil: ‘high’, ‘neutral’, ‘low’ or ‘needing reparation’ (very

low P status) as determined by soil analysis (Tables 12 and 13). The limits in 2015 for soils with a

neutral phosphorus status approximate the average phosphorus export of the harvest. On soils with

a phosphorus content lower or higher than the neutral status, more or less phosphorus, respectively,

can be applied than the maximum P application rate for soils with neutral P status. The phosphorus

status is voluntarily measured at least every four years by ammonium lactate extraction (grassland)

or water extraction (arable land). Non-analysed soils are assumed to have a high phosphorus status

(lowest P application standards). In 2013, 56% of the Dutch grassland area was categorized as ‘high’

(80% assumed by lack of analysis), 30% as ‘neutral’ and 14% as ‘low’. For arable land this was 63%

high (93% assumed), 23% neutral and 14% low (Willems & Schröder, 2013).

Table 12. Maximum phosphorus application standards for grasslands in the Netherlands, depending on the soil

phosphorus status (ammonium lactate extraction).

Phosphorus status

High

Neutral

Low

Needing reparation

P-AL

(mg P

/100 g)

> 50

27 – 50

< 27

< 16

Limit (kg P

/ha/y)

2014

2015-2017

80*

90*

100

120

* To be confirmed by general administrative order.

For a maximum of 4 years

Table 13. Maximum phosphorus application standards for arable crops in the Netherlands, depending on the

soil phosphorus status (water extraction).

Phosphorus status

High

Neutral

Low

Needing reparation

(mg P

/l)

> 55

36 – 55

< 36

< 25

Limit (kg P

/ha/y)

2014

2015-2017

50*

60*

120

* To be confirmed by general administrative order.

For a maximum of 4 years

The limits for soils needing reparation (grassland P-AL < 16 mg P

/100 g or arable land Pw < 25) are

120 kg P

/ha/y during a period of 4 years maximum). The limits for grasslands with phosphorus

status ‘low’ are fixed for 2014-2017 (100 kg P

/ha/y; Table 12). The limits for arable soils (all

categories of soil P status) and grassland soils (phosphorus status high and neutral) will decrease by

5 kg P

/ha/y in 2015 (Table 13).

PDF to HTML - Convert PDF files to HTML files

3.25.3 Deviations from the general limits

A farmer can apply a maximum of 20 kg P

/ha/y above the stated limits, providing that this surplus

is compensated by lower phosphate application(s) in the next year.

Only 50% of phosphorus applied via compost is taken into account by Dutch legislation because

compost has a considerable soil fraction. This exemption is limited to 3.5 kg P

/1000 kg.

3.25.4 Other

Part of the farm phosphorus surplus (manure) must be processed or exported. The percentage of the

farm phosphorus surplus that has to be processed or exported varies per region (these are related to

the manure concentration areas). For 2014 the values are 30% (South), 15% (East) and 5% (other).

The values are defined annually by the ministry of Economic Affairs.

No subsidies are given to farmers that voluntarily apply less phosphorus than legally allowed.

PDF to HTML - Convert PDF files to HTML files

4.1

Discussion

General

Limiting the P application by maximum application rates is one of the ways to reduce the direct risk

of P losses to surface waters. General legislation concerning the use of manure or fertilisers can also

indirectly limit the P use in agriculture. In Nitrate Vulnerable Zones (NVZ) the application of manure is

restricted to 170 kg N/ha/y or a higher value in case of derogation. This tends to limit the P

application by manure, depending on the N/P ratio of the applied manure. The implementations of

the Nitrates Directive also contain periods when (see also Figure 2 and Appendix 3), places where

farmers may not apply fertilisers, and restrictions to the manner in which fertiliser is applied in NVZs.

Other regulations can limit land application of waste water treatment sludge, impose measures for

limiting erosion losses, etc. which all indirectly contribute to less P losses from agriculture towards

surface waters.

Belgium (Flanders)

Belgium (Wallonia)

Denmark

England

France (Brittany)

Germany

Italy (Piemonte)

Poland

Spain (Murcia)

The Netherlands

1 Aug

1 Sep

1 Oct

1 Nov

1 Dec

1 Jan

1 Feb

1 Mar

Mineral

Liquid manure

Solid manure

Figure 2. General overview of periods within no mineral (blue), liquid manure (green) and solid manure (orange)

can be applied on grasslands in Nitrate Vulnerable Zones (adapted from Hofman et al., 2013)

Direct regulations for phosphorus applications on agricultural land differ widely across European

countries and regions. Some countries have no explicitly-stated regulations concerning phosphorus

while others have detailed maximum application standards depending upon the crop and/or the soil

phosphorus status. The various systems used, e.g. maximum application standards, balance system,

etc., complicate the efforts to compare regulations across nations/regions. Even within the system of

maximum application standards there are different subjects of regulation: total P, only manure P or

PDF to HTML - Convert PDF files to HTML files

only chemical fertiliser P (see 4.2). Table 14 presents an overview of the different systems and limits.

All application rates are reported in kg P

/ha/y units. To switch from kg P/ha/y to P

/ha/y units,

rates have to be multiplied by 2.29. Within the system of maximum application standards for total

phosphorus, Flanders and Brittany have the lowest maximum limits (95 kg P

/ha/y). Ireland has the

lowest minimum limit: for certain crops planted on soils with the highest phosphorus status, the

phosphorus application limit is zero.

The extent of the phosphorus legislation and the severity of the application limits is largely related to

the ecological condition of the national or regional water bodies. Countries with no (or limited)

phosphorus legislation often argue that there are no phosphorus problems in their country.

Countries or regions with strict application limits have a history of large phosphorus applications,

resulting in large soil phosphorus contents (Figure 3) and a majority of the water bodies with a less

than good ecological status or potential (Figure 1). This is especially the case in NW European

countries. Nevertheless, some of the countries and regions in Europe with high phosphorus contents

in soil and high P concentrations in surface waters do not have an extensive phosphorus legislation,

e.g. parts of England, Wales, Poland, France, etc.

Figure 3. Olsen P concentration categories of cropland soils in the EU 2009-2012, based on the LUCAS topsoil

survey (Tóth et al., 2014).White: no data; light yellow: very low; yellow: low; red: medium; blue: high; black:

very high.

PDF to HTML - Convert PDF files to HTML files

Table 14. Overview of phosphorus legislation per country/region (limits in kg P

/ha/y; divide by 2.29 to get

units in kg P/ha/y)

Country/region

Austria

Belgium

Flanders

Belgium

–

Wallonia

Czech Republic

Denmark

England, Scot-

land and Wales

Estonia

P applica-

tion limits?

– Yes

Yes

Regulation

system

Max. rates

type

regulated

Total P

Manure P

Extra

chemical P

Total P

Limits

(kg Limits depend upon

/ha/y)

40–95

Crop type, phosphate

saturated soil or not

5–224

Finland

France – Brittany

Germany

Greece

Hungary

Ireland

Israel

Latvia

Luxembourg

Northern Ireland

Norway

Poland

Spain

Sweden

The Netherlands

AEP

Yes

AEP

Yes

Max. rates

Max. rates Total P

or balance

Balance

Total P

Max. rates

Total P

Chemical

fertiliser P

Manure P

Total P

Crop type, yield and

soil P

Soil P, crop type and

0–252

yield

80–95

or Farm type and water

export + 10% basin, or crop export

export + 20

Balance (crop yield

and export) and soil P

0–286

Crop type and soil P

(and yield for cereals)

Soil P, crop type and

0–186

yield

0–250

Advice (soil P, crop

type and yield)

55–120

Soil P (and crop: grass

or arable crop)

AEP: No strict regulations but requested in Agri-Environmental Programme (95% participation in Finland and

Luxembourg)

Only indirect limitation of phosphorus in manure applied in Nitrate Vulnerable Zones (or whole territory for

some countries) by the limit of 170 kg N/ha/y (140 kg N/ha/y for most animals in Denmark)

Restrictions on manure P surplus; only for animal farms that want to expand or change and that drain into

Nature 2000 areas that are overloaded with P

and

that fall under class 1, 2 or 3 (see details in Denmark section)

Higher limits possible for higher than average crop yields

Except for the Extremadura region: limit of 80 kg P

/ha/y for olive, rice, tobacco and deciduous fruit trees.

Manure P (Luxemburg) and organic P fertiliser (Northern Ireland) only restricted if combined with chemical P

fertiliser

Scotland: fertilisers must not be applied to land in excess of the nutrient needs of the crop.

PDF to HTML - Convert PDF files to HTML files

In addition to the differences in legislation, the control systems embedded in these regulations differ

widely among European countries. Some regulations lack specificity and real enforcement (Ekardt et

al., 2011). As an example, not all European countries require mandatory submission of information

about nutrient management to the authorities. This affects the degree of compliance with the

regulations. In the context of implementation of the Nitrates Directive, penalties, inspection rates

(1% to more than 5%) and annual updates of the control action plans differ widely among Member

States (Schils & Velthof, 2011).

4.2

Type of restricted phosphorus application

Not all types of phosphorus applications to agricultural land are limited by the various regulations

(Table 15). Most of the countries or regions with phosphorus application standards limit all types of

phosphorus fertilisation, but this is not the case for Northern Ireland (only chemical fertilisers and

other applications in combination with chemical P fertiliser), Luxembourg (manure P is only taken

into account when applied in combination with other fertilisation), Sweden (only P in organic

fertilisers), Norway (only manure P), Denmark (only organic fertilisers consisting of less than 75%

manure) and Latvia (only WWTP sludge). In Ireland, only 50% of P in organic fertilisers must be taken

into account for application on soils with low P content (index 1 and 2). In the Netherlands and

Flanders (Belgium), only 50% of compost P must be taken into account. In Finland, not all P from

manure, sludge and compost has to be taken into account (see Table 15).

4.3

Limits for different crops

Some countries or regions have general phosphorus application standards, while in other countries

the phosphorus application standards depend upon the crop cultivated (see last column of Table 14).

Phosphorus application standards for the main crops are compared for the different countries and

regions (Table 16). The standards presented in Table 16 are valid for soils with moderate P content,

which is of course not exactly the same for all countries and regions (for legislation with standards

that depend upon soil P status, see 4.4). Maximum phosphorus application standards are generally

more strict in northwestern Europe, where a large fraction of the surface waters is not in good

ecological condition (see left map in Figure 1). However, not all countries with large phosphorus

concentrations in surface waters limit phosphorus fertilisation. Another important factor that

determines the extent of the limits is the average national crop yield. The allowed phosphorus inputs

increase along with the increasing phosphorus export by the crop, and therefore the increasing crop

yield, in cases where the goal is equilibrium fertilisation. This can explain the higher phosphorus

application limits for countries or regions with intensive agriculture.

Many European countries do not have any maximum phosphorus application standards. For the

countries and regions that do have standards, the maximum application standard for grassland are

highest for Flanders (Belgium), Brittany (France) and the Netherlands, all intensive agriculture areas

(Table 16). Differences between countries and regions are smaller for maize, cereals and sugar beets.

Potatoes, a phosphorus-sensitive crop, have much higher maximum application standards than other

crops in Estonia, Finland, Ireland and Northern Ireland.

PDF to HTML - Convert PDF files to HTML files

Table 15. Types of phosphorus application limited by the various countries and regions (x: included in

restrictions, -: not included; limits in kg P

/ha/y, divide by 2.29 to get units in kg P/ha/y)

Country/region

Austria

Belgium – Flanders

Belgium – Wallonia

Czech Republic

Denmark

England, Scotland

and Wales

Estonia

Finland

France – Brittany

Germany

Greece

Hungary

Ireland

Israel

Latvia

Luxembourg

Northern Ireland

Norway

Poland

Spain

Sweden

The Netherlands

Limits (kg

/ha/y)

40–95

5–224

0–252

80–95 or

export + 10%

export + 20

0–286

0–186

0–250

55–120

Limits refer to P in

Chemical

fertiliser

Manure

x (40-85%)

WWTP sludge

x (40%)

Compost

x (50%)

x (40-100%)

x (50 or 100% ) x (50 or 100% ) x (50 or 100%

)

abc

(x)

x (50%)

Less than 10% of WWTP sludge has acceptable levels of metals and organic pollutants

50% for low soil P content (index 1 and 2), 100% for high soil P content (index 3 and 4)

Only restricted if this type of fertilisation is combined with chemical P fertiliser

Indirect limitation of phosphorus in manure applied in Nitrate Vulnerable Zones (or the entire territory for

some countries) by the limit of 170 kg N/ha/y (140 kg N/ha/y in some cases in Denmark)

AEP: No strict regulations but requested in the Agri-Environmental Programme (95% participation in Finland

and Luxembourg)

85% for manure, 40% for fur-animal manure (foxes, minks, finnraccoons and fitchets), compost: depending on

starting material. Will probably increase to 100% (manure) and 60% (fur-animal manure and sludge) from 2015

on.

Restrictions on manure phosphorus surplus; only for animal farms that want to expand or change and that

drain into Nature 2000 areas that are overloaded with P

and

that fall under class 1, 2 or 3 (see details in

Denmark section)

Higher limits possible for higher than average crop yields

Scotland: fertilisers must not be applied to land in excess of the nutrient needs of the crop.

Except for the Extremadura region: limit of 80 kg P

/ha/y for olive, rice, tobacco and deciduous fruit trees.

PDF to HTML - Convert PDF files to HTML files

Table 16. Phosphorus application standards for various crops at a moderate soil P status (limits in kg P

/ha/y;

divide by 2.29 to get units in kg P/ha/y)

Country/region

Austria

Belgium – Flanders

Belgium –Wallonia

Czech Republic

Denmark

England,

Scot-

land and Wales

Estonia

Finland

France – Brittany

Germany

Greece

Hungary

Ireland

Israel

Latvia

Luxembourg

Northern Ireland

Norway

Poland

Spain

Sweden

The Netherlands

Grassland

57 (manure)

46–60 (+ch)*

18–55

80–95 or

export + 10%

export + 20

25–71

40–88

acd

20–90

Maize

57 (manure)

69 (+ ch)*

80–95 or

export + 10%

export + 20

120–126

acd

Cereals

70–75

57 (manure)

34–66

(+ch)*

18–32

80–95 or

export + 10%

export + 20

60–65

acd

45–65

Potatoes

57 (manure)

126–149

(+ch)

126

80–95 or

export + 10%

export + 20

172

102

acd

170

Sugar beet

57 (manure)

80–95 or

export +10%

export + 20

* Crop requirement, can be given on top of manure P by chemical fertiliser

Manure P (Luxemburg) and organic P fertiliser (Northern Ireland) only restricted by these limits if combined

with chemical P fertiliser

Only manure P (Norway) or P from organic fertilisers (Sweden), for total area

AEP: No strict regulations but requested in Agri-Environmental Programme (95% participation in Finland and

Luxembourg).

Limits are higher for higher yields in Estonia, Finland, Ireland, Luxembourg and Northern Ireland. In Estonia,

Luxembourg and Northern Ireland: also lower limits for lower yields.

Scotland: fertilisers must not be applied to land in excess of the nutrient needs of the crop.

Restrictions on manure phosphorus surplus; only for animal farms that want to expand or change and that

drain into Nature 2000 areas that are overloaded with P

and

that fall under class 1, 2 or 3 (see details in

Denmark section)

4.4

Taking the phosphorus status of soils into

account

The risk for phosphorus losses from agricultural soils towards surface waters and groundwaters

varies strongly from field to field. The main goal of agricultural phosphorus legislation is to reduce

phosphorus losses towards water bodies. Therefore, one can argue that limiting phosphorus

PDF to HTML - Convert PDF files to HTML files

application should be linked to the risk for phosphorus losses. Targeting phosphorus fertilisation in

the high-risk areas will probably give the best or fastest improvement in water quality. Phosphorus

losses depend upon the availability of P (soil P status and P fertilisation), transport possibilities

(slope, soil texture, subsurface drainage, etc.) and connectivity to the receiving waters. These factors

are all considered in the Phosphorus Index (Heathwaite et al., 2003), although some doubts have

been expressed about the suitability of the index for areas where P transport mainly occurs through

leaching (Schoumans et al., 2013). There are no European countries or regions where the maximum P

application standards depend upon the P Index or another combination of the abovementioned

factors. The connectivity and erosion losses can be addressed by installing a buffer zone (no P

fertilisation) along waterways, as many countries have already implemented (Table 17). As an

alternative for the P Index, maximum phosphorus application standards can depend upon the soil

phosphorus content, which is an important factor in phosphorus loss (Sharpley & Rekolainen, 1997;

Tunney, 2002; Rubaek et al., 2010). Many methods are used to measure the soil phosphorus

concentration, from mild extractions (by water) to relatively harsh extractions (e.g. oxalate

extraction). Most of the methods for soil P measurement are developed for agricultural purposes, i.e.

estimation of the availability of P for the crop, and not for environmental goals, i.e. risk for P losses.

The countries or regions with stricter P application regulations for soils with a higher soil P status are

the Netherlands, Ireland, Finland (AEP), Luxembourg (AEP), Northern Ireland (only chemical P

fertiliser) and Estonia (only chemical P fertiliser in addition to manure P). In Denmark, stricter

regulations for manure surplus are applicable at larger soil Olsen-P content for farms that want to

expand or change and that drain into Natura 2000 areas overloaded with P. In the Netherlands, 3 (4)

soil P classes are defined based upon ammonium lactate extraction (grasslands) or water extraction

(arable land). Extraction by ammonium lactate is an agricultural method; water extraction is used

both for agricultural and environmental purposes. Ireland has 4 classes defined by Morgan’s

extraction (weakly acidic, agricultural method). In Northern Ireland, the agricultural Olsen P method

is used. In Finland, which uses an acid ammonium acetate extraction (pH 4.65), the fertility class also

depends upon the soil texture and the organic matter content. In Estonia, an agricultural method

(Mehlich 3 extraction) is used. In Luxembourg, the agricultural calcium acetate lactate extraction is

applied. Comparison of the different limits of soil P classes is not possible given the differences in

extraction methods and soil sampling depth. Factors for converting the result of one method to

another method depend highly upon soil characteristics and are therefore not generally valid

(Schoumans, 1997; Sibbesen & Sharpley, 1997; Otabbong et al., 2009).

Flanders (Belgium) has a reduced maximum fertilisation standard (40 kg P

/ha/y) for a small

phosphate-saturated area (0.6–1% of agricultural area). The method for measuring the phosphate

saturation degree (PSD) was developed for environmental purposes. It is based on the relationship

between the phosphate saturation degree of a soil and the molybdate reactive phosphorus (MRP)

concentration in the leachate. Based on a generally acceptable concentration of 0.1 mg MRP/l for

surface waters, a limit of 25% PSD was derived (van der Zee et al., 1990b). In Flanders, the PSD limit

is set at 35%. Measurements of drainage water in 19 Flemish fields revealed that none exceeded the

0.1 mg MRP/l limit at PSD < 35% (Brookes et al., 1997). However, possible increases in phosphorus

drainage concentrations over time were not taken into account. The phosphate-saturated area in

Flanders is small because of the higher limit of 35% (compared to 25%), the necessity of 95%

probability of exceeding the 35% threshold, and the fact that the protocol for PSD measurement is

only valid for non-calcareous light-textured soils (only half of Flanders’ agricultural area). In the

PDF to HTML - Convert PDF files to HTML files

Netherlands, 56% of the agricultural area is phosphate-saturated (>25%) (Schoumans, 2004), but this

has no legislative implications.

Standard application rates depending upon the soil phosphorus status have as a result that soils with

high phosphorus contents will accumulate less P or that the phosphorus content will diminish over

time. Consequently, efforts aimed at the highest-risk soils will result in reduced P risks while

equilibrium fertilisation on soils with acceptable P levels will assure optimal crop yields. In the

Netherlands, Ireland, Northern Ireland, Germany, Finland, Luxembourg and Estonia, more

phosphorus can be applied to soils with low phosphorus status. This enables farmers to gradually

increase the soil phosphorus content in order to obtain optimal yields. Of course the rate of the

transition of soils with low and high P levels towards an optimal P level will depend upon the extent

of the difference between the maximum P application standard and the crop P export. Large

differences (large net P inputs for low P soils or large net P outputs for high P soils) will induce faster

changes in the soil P content. These net inputs and outputs are rather small in the Netherlands, as

reflected by the small range of maximum P application rates, i.e. 55–120 kg P

/ha/y for arable

crops and 85-120 kg P

/ha/y for grasslands. In contrast, the net P inputs and outputs in Ireland are

large, as for some crops no P application is allowed for index 4 soils (net output equals P export by

the crop) and the maximum P application rate for index 1 soils is very high (see Tables 7 and 8).

However, given the importance of hydrology and connectivity between field and water body, there is

no 1:1 relationship between the soil phosphorus content of a field and phosphorus losses from the

field to surface water. Currently, no national or regional legislation takes the latter two factors into

account, but they should be part of an effective P risk approach. Legislative measures based on a

more environmental approach to phosphorus fertilisation restrictions would be more effective when

attempting to influence the phosphorus concentrations in surface waters.

4.5

Constraints for farmers

Countries or regions with detailed legislation generally have large agricultural phosphorus losses and

a large fraction of soils with high phosphorus status. More phosphorus than required for crop

production was or is applied because of uncertainty about soil phosphorus status, insurance for

optimal crop yields and/or a farm manure surplus. Manure generally has a N/P ratio between 2 and

8, in contrast to the N/P ratio of 7 – 11 required by crops. When the crop’s N requirement is applied

by using solely manure, this results in an excess of P.

Crops do not suffer from high soil P contents. Apart from the economic cost of chemical fertiliser, a

farmer has no incentive to limit the P application. In regions without manure surplus, the availability

of good fertilisation advice (Jordan-Meille et al., 2012) and encouragement to measure the soil P

status can already limit the P application. But for farms with manure surpluses, fertilisation

restrictions affect farmers’ practices and income. Moreover, manure is considered a main

contributor to organic matter build-up in the soil and substantial restrictions on manure application

can therefore limit the maintenance of the organic matter content which can influence the soil

properties.

Maximum phosphorus application rates are often set by general crop requirements or crop P

exports. Crop requirements are often higher than the export of P by harvest for crops with a low root

density (e.g. endive, spinach, potatoes, onions, etc). Higher yields and P exports are often established

PDF to HTML - Convert PDF files to HTML files

by very intensive farming. This is taken into account using balance systems, where phosphorus limits

vary according to the crop yield (and in some cases also the crop P content). Balance systems are

used in Germany and in some cases in Brittany (France). In Ireland the maximum application

standard for cereals increases at higher yields. This is also the case in the Agri-Environmental

Programmes of Finland (cereals, rye and oil plants) and Luxembourg. In Northern Ireland, maximum

P application rates by chemical fertiliser increase or decrease at higher or lower yields, except for

potatoes. In Estonia, the chemical P fertiliser dose that can be applied depends upon the predicted

yield. Balance systems also take multiple crops in one year into account since the P export by all

crops is calculated. In Ireland and Northern Ireland, the maximum P application standard of one year

is the sum of the maximum P application standards of all crops cultivated in that year. In Belgium

(Flanders) and the Netherlands, maximum standards do not increase if more than one crop is

cultivated in one year, with the exception of one cut of grass or rye followed by maize in Flanders.

PDF to HTML - Convert PDF files to HTML files

4.6

Additional legislation

In addition to general fertiliser restrictions (see above), other regulations also address phosphorus application. In the Netherlands and Flanders (Belgium),

part of the farm manure surplus must be processed or exported. In Flanders, this farm manure surplus is based on N production, but in the Netherlands it is

based on the phosphorus farm balance.

The main risk related to phosphorus fertilisation is the eutrophication of surface waters. Most European countries have buffer zones along waterways or

sources where no fertilisation is allowed. The width of this buffer zone differs widely among the Member States, i.e. from 0.5 m to 500 m (Table 17). Buffer

zone width varies with fertilisation type: some countries or regions require a larger width for manures than for chemical fertiliser. The buffer zone width can

also vary depending upon the water body type: larger water bodies require wider buffer zones. Larger widths are sometimes requested for more vulnerable

areas and sloping land. Wider buffer zones are installed around abstraction points for human water consumption. Some Member States have no restrictions

outside the NVZs except under Agri-Environmental Programmes or Cross Compliance. In almost all countries and regions the buffer zone area can be

included in the total area for fertilisation calculations of the field, except in Denmark.

Table 17. Buffer zone regulations in the European countries/regions

Country/

Region

Austria

Belgium

Flanders

Belgium

Wallonia

Czech

Republic

Fertiliser

restricted

All types

– All types

–

Manure

type

distance

(m)

No-fertilisation buffer zone from a water body

Where/What kind of waterways

Permanent waterway

Waterways of all categories, smaller ditches usually not included

Waterways located in Flemish Ecological Network or next to a slope of >8%

Waterways

Any surface water in NVZs and for farmers under the agri-environmental programme

Any surface water with land slope > 7° in NVZs and for farmers under the agri-

environmental programme

Streams and lakes with surface area > 100 m². The buffer zone area can be reduced to

5% of the total farm area if the 10 m buffer zone area is > 5%.

Grazing allowed?

Yes

All types

Liquid fertilisers

with fast N release

(liquid manure,

ammonia)

All types

Denmark

(cont p 33)

Yes

PDF to HTML - Convert PDF files to HTML files

Denmark

(cont p 32)

England

Wales

and

All types

Inorganic fertiliser

Organic manure

10 (6)

5 (10)

35 (10)

100

500

200

500

3 (1)

0.5

Estonia

All types

Finland

N fertiliser

All types

France

Brittany

– Mineral fertiliser

Solid and

composted manure

Liquid manure

Streams and lakes with surface area > 100 m² if slope >6°. If the slope is between 6° and

12°, it is allowed to use liquid mineral fertilisers and manure injected parallel with the

stream/lake between 10 and 20 m distance of the stream/lake.

Any controlled water (includes freshwater streams, rivers, ditches, lakes) within a NVZ,

and outside a NVZ for Single Farm Payment or Agri-Environment Subsidies

Any controlled water (includes freshwater streams, rivers, ditches, lakes) within a NVZ,

and outside a NVZ for Single Farm Payment or Agri-Environment Subsidies. Limit of 6 m

for precision spraying equipment.

Drainage systems with catchment area < 10 km²

Other lakes, rivers, streams, springs and channels

Baltic Sea and two largest lakes (Peipsi and Võrtsjärv)

Waterways (10 m if slope > 2%)

Main ditches

Brooks, water courses, rivers, lakes, sea and household wells

All waterways and conditions

Waterways (10 meter if a grass strip is present)

Waterways when slope > 5% (except if slope <15% + hedgerows present: 35 m)

Fish farming

Water abstraction point for human consumption

Bathing, beaches

Shell production areas (coast)

All waterways. Reduction to 1 m in the case of exact application techniques and slope

<10%.

Irrigation canals, ditches, wells and boreholes

Rivers, streams, lakes

Surface waters in NVZs

Lakes in NVZs

Other surface waters in NVZs (3 if the plot width ≤ 50 m and plot area ≤ 1 ha)

Springs, wells used for drinking water supply in NVZs

Yes

Yes, except if the

buffer zone is

registered as

fallow land

All manures

Germany

Greece

Hungary

All types

Chemical fertilisers

Manure

Yes

PDF to HTML - Convert PDF files to HTML files

Ireland

Chemical P

fertiliser

100/200

Any surface water

Abstraction point of any surface water for human consumption in a water scheme

supplying 10/100 m³/day or more, or serving 50/500 or more persons/day

Any borehole, spring or well used for abstraction of water for human consumption

other than mentioned above

Lake shoreline

Exposed cavernous or karstified limestone features

Other surface waters than mentioned above

Other surface waters, where the land has an average incline > 10%

Other surface waters, two weeks before and after periods closed for fertiliser

application

All rivers with length > 10 km, lakes with surface area > 10 ha. Exact width of buffer

zone depends upon the importance of the surface water (e.g. Daugava river: 500 m).

Width of buffer zones for groundwater abstraction points can be designated according

to local conditions.

Any waterway through which water flows

Lakes

Borehole, spring or well

Borehole for a public water supply

Exposed, cavernous or karstified, limestone features

Any waterway through which water flows, other than lakes, including open areas of

water, open field drains or any drain which has been backfilled to the surface with

permeable material such as stone/aggregate, except in cases below

Waterways where the land has an average incline < 10%, organic manure is spread by

band spreader, trailing hose, trailing shoe or soil injection, or the adjoining area is < 1

ha in size and not > 50 m in width

Any waterway. Two metres is mandatory; subsidies (depending on the region and year)

are given for 8-10 metres.

Yes

Organic fertiliser or

soiled water

Yes

Latvia

Fertilisers and PPP

Northern

Ireland

Chemical P

fertiliser

10 and

1.5

250

Manure

Yes

Norway

All types

PDF to HTML - Convert PDF files to HTML files

Poland

Fertilisers

excluding slurry

Slurry

All types

2−5

−

Lakes and reservoirs < 50 ha, water courses, ditches (< 5 m width), channels. Connected

with direct support schemes for farmers.

Lakes and reservoirs > 50 ha, water intake protection zones, coast (Baltic Sea).

Connected with direct support schemes for farmers.

Subsidy for buffer zones along streams

Most of the regional implementations of agro-environmental measures considers the

"maintenance of uncropped borders and zones" in some cases around watercourses to

"promote biological diversity"

Any river, burn, ditch, wetland, loch, transitional water or coastal water

Spring that supplies water for human consumption or any well or borehole that is not

capped to prevent water ingress

Spring that supplies water for human consumption or any well or borehole that is not

capped to prevent water ingress

Brooks, streams, rivers, canals or weirs (small dams) within a NVZ, and outside a NVZ

for Cross Compliance

Designated brooks in the uplands of the sandy districts of the Netherlands

Yes

−

Significant

erosion or

poaching must be

prevented (5 m)

Yes

Spain

All types

Scotland

Inorganic fertiliser

Organic fertiliser

Livestock access

Sweden

The

Netherlands

All types

Similar distances in other NVZs of France

AEP: No strict regulations but requested in Agri-Environmental Programme (95% participation)

German regions (Laender) can have stricter regional standards, e.g. 5 m buffer strip in Baden-Württemberg according to the regional Water Act

These types of buffer zones are usually promoted in areas of special ecological interest: borders of natural reserves, in some cases in watercourses, in areas of special

interest for birds, etc.

PDF to HTML - Convert PDF files to HTML files

References

Anon. 2004a. Lov om afgift af mineralsk fosfor i foderfosfat.

Anon. 2004b. Water Act of Estonia (Veeseadus).

Anon. 2006a. Bekendtgorelse om anvendelse af affald til jordbrugsformal (Slambekendtgorelsen).

Anon. 2006b. Statutory rules of Northern Ireland, 2006 No. 488, Phosphorus (Use in Agriculture)

Regulations (Northern Ireland) 2006.

Anon. 2007a. Düngemittelverordnung. Bekanntmachung der Neufassung der Düngeverordnung

Bundesgesetzblatt : Teil 1 / Bundesminister der Justiz.

Anon. 2007b. Opas ympäristötuen ehtojen mukaiseen lannoitukseen 2007-2013. Mavi, Seinäjoki,

Finland.

Anon. 2008. Towards the 50% reduction target for nutrients. Assessment of Implementation of

PARCOM Recommendations 88/2 and 89/4. OSPAR Commission, London.

Anon. 2009a. Arrêté préfectoral de la directive nitrates de Maine-et-Loire (30/06/2009).

Anon. 2009b. Düngegesetz vom 9. Januar 2009. Bundesgesetzblatt: Teil 1 / Bundesminister der Justiz.

Anon. 2009c. Fertilisation PK. Comifer, France.

Anon. 2009d. Schéma directeur d'aménagement et de gestion des eaux (Sdage) du bassin Loire-

Bretagne 2010-2015.

Anon. 2010a. Fertiliser Manual (RB209), 8th Edition. The Stationary Office, Department for

Environment Food and Rural Affairs, Norwich, UK.

Anon. 2010b. Statutory rules of Northern Ireland. 2010 No. 411. Environmental protection, The

Nitrates Action Programme Regulations (Northern Ireland) 2010.

Anon. 2011. Decreet van 22 december 2006 houdende de bescherming van water tegen de

verontreiniging door nitraten uit agrarische bronnen.

Anon. 2012a. Arrête du 7 février 2005 fixant les règles auxquelles doivent satisfaire les élevages de

bovins, de volailles et/ou de gibier à plumes et de porcs soumis à autorisation au titre du

livre V du code de l'environnement.

Anon. 14-11-2012b. Commission staff working document, European Overview (1/2), accompanying

the document Report from the Commission to the European Parliament and the Council on

the implementation of the Water Framework Directive (2000/60/EC), River Basin

Management Plans (COM(2012) 670). European Commission, Brussel.

Anon. 2013a. Beskyttelsesniveau for ammoniak, lugt, fosforoverskud og nitrat. Bilag 3 of BEK nr 1280

af 08/11/2013 (Husdyrgodkendelsesbekendtgorelsen).

PDF to HTML - Convert PDF files to HTML files

Anon. 2013b. Communication from the Commission to the European Parliament, the Council, the

European Economic and Social Committee and the Committee of the Regions. Consultive

communication on the sustainable use of phosphorus. European Commission, Brussel.

Anon. 2013c. The Water Environment (Controlled Activities) (Scotland) Regulations 2011,

Amendment Regulations 2013.

Anon. 2013d. Vejledning om godsknings- og harmoniregler. Planperioden 1. august 2013 til 31. juli

2014. Ministeriet for Fodevarer, Landbrug og Fiskeri, Kopenhagen.

Anon. 2014a. European communities (good agricultural practice for protection of waters) regulations

2014.

Anon. 2014b. Informationsbroschüre landschaftspflegeprämie. Ministère de l'Agriculture, de la

Viticulture and du Développement Rural, Luxembourg.

Anon. 2014c. Meststoffenwet. Wet van 27 november 1986, houdende regelen inzake het

verhandelen van meststoffen en de afvoer van mestoverschotten.

Anon. 2014d. Uitvoeringsregeling meststoffenwet.

Bogestrand, J., Kristensen, P., Kronvang, B. 2005. Source apportionment of nitrogen and phosphorus

inputs into the aquatic environment. European Environment Agency, Copenhagen.

Brookes, P.C., Heckrath, G., De Smet, J., Hofman, G., Vanderdeelen, J. 1997. Losses of phosphorus in

drainage water. 253-271. Phosphorus loss from soil to water (Tunney, H., Carton, O.T.,

Brookes, P.C. and Johnston, A.E.). CAB International, Cambridge.

Cordell, D., Drangert, J.O., White, S. 2009. The story of phosphorus: Global food security and food for

thought. Global Environmental Change-Human and Policy Dimensions, 19, 292-305.

Damgaard Poulson, H. 2005. Normtal for husdyrgodning - 2005, 23 sider. Aarhus Universitet, Aarhus.

Damgaard Poulson, H. 2013. Normtal for husdyrgodning - 2013, 33 sider. Aarhus Universitet, Aarhus.

Ekardt, F., Holzapfel, N., Ulrich, A.E., Schnug, E., Haneklaus, S. 2011. Legal perspectives on regulating

phosphorus fertilization. Landbauforschung, 61, 83-92.

Heathwaite, L., Sharpley, A., Bechmann, M. 2003. The conceptual basis for a decision support

framework to assess the risk of phosphorus loss at the field scale across Europe. Journal of

Plant Nutrition and Soil Science-Zeitschrift fur Pflanzenernahrung und Bodenkunde, 166, 447-

458.

Hofman, G., De Vis, R., Crappé, S., Van de Sande, T., Mechant, E., D'Haene, K., Amery, F.,

Vandecasteele, B., Willekens, K., De Neve, S. 2013. Benchmark study on nutrient legislation

for horticultural crops in some European countries. Nutrihort: Proceedings: Nutrient

management, Innovative Techniques and Nutrient Legislation in Intensive Horticulture for an

Improved Water Quality, 211-227. Nutrihort, Merelbeke.

Jordan-Meille, L., Rubaek, G.H., Ehlert, P.A.I., Genot, V., Hofman, G., Goulding, K., Recknagel, J.,

Provolo, G., Barraclough, P. 2012. An overview of fertilizer-P recommendations in Europe:

soil testing, calibration and fertilizer recommendations. Soil Use and Management, 28, 419-

435.

PDF to HTML - Convert PDF files to HTML files

Kerschberger, M., Hege, U., Jungk, A. 1997. Standpunkt "Phosphordüngung nach Bodenuntersuchung

und Pflanzenbedarf". Verband Deutscher Landwirtschaftlicher Untersuchungs- und

Forschungsanstalten, Darmstadt.

Kristensen, P. 2012. European waters - assessment of status and pressures. European Environment

Agency, Copenhagen.

Otabbong, E., Borling, K., Katterer, T., Mattsson, L. 2009. Compatibility of the ammonium lactate (AL)

and sodium bicarbonate (Olsen) methods for determining available phosphorus in Swedish

soils. Acta Agriculturae Scandinavica Section B-Soil and Plant Science, 59, 373-378.

PMK 2013. Väetistarbe gradatsioon (in Estonian). The gradation of fertiliser. Estonian Agricultural

Research Centre, Saku.

Rubaek, G.H., Kjaergaard, C., Glaesner, N., Heckrath, G., Magid, J. 2010. Adapting agricultural practice

to minimize P leaching. 6th International Phosphorus Workshop, IPW6, Sevilla.

Schils, R., Velthof, G. 2011. Controls on the implementation of the Nitrate Directive. Results of a

questionnaire among Member States. Guidelines on Controls. Alterra Wageningen UR,

Wageningen.

Schoumans, O. 2004. Inventarisatie van de fosfaatverzadiging van landbouwgronden in Nederland.

Report 730.4, Alterra, Wageningen.

Schoumans, O.F. 1997. Relation between phosphate accumulation, soil P levels and P leaching in

agricultural land. Report 146, DLO Winand Staring Centre, Wageningen.

Schoumans, O.F., Chardon, W.J., Bechmann, M., Gascuel-Odoux, C., Hofman, G., Kronvang, B., Litaor,

M.I., Lo Porto, A., Newell-Price, P., Rubaek, G.H. 2011. Mitigation options for reducing

nutrient emissions from agriculture. A study amongst European member states of Cost action

869. Report 2141, (Schoumans, O.F. and Chardon, W.J.). Alterra, Wageningen.

Schoumans, O.F., Chardon, W.J., Bechmann, M.E., Gascuel-Odoux, C., Hofman, G., Kronvang, B.,

Rubaek, G.H., Ulén, B. 2014. Mitigation options to reduce phosphorus losses from the

agricultural sector and improve surface water quality: A review. Science of the Total

Environment, 468-469, 1255-1266.

Schoumans, O.F., van der Salm, C., Groenendijk, P. 2013. PLEASE: a simple model to determine P

losses by leaching. Soil Use and Management, 29, 138-146.

Schröder, J.J., Smit, A.L., Cordell, D., Rosemarin, A. 2011. Improved phosphorus use efficiency in

agriculture: A key requirement for its sustainable use. Chemosphere, 84, 822-831.

Sharpley, A.N., Rekolainen, S. 1997. Phosporus in agriculture and its environmental implications. 1-

53. Phosphorus loss from soil to water (Tunney, H., Carton, O.T., Brookes, P.C. and Johnston,

A.E.). CAB International, Cambridge.

Sibbesen, E., Sharpley, A.N. 1997. Setting and justifying upper critical limits for phosphorus in soils.

151-176. Phosphorus loss from soil to water (Tunney, H., Carton, O.T., Brookes, P.C. and

Johnston, A.E.). CAB International, Cambridge.

PDF to HTML - Convert PDF files to HTML files

Tóth, G., Guicharnaud, R.-A., Tóth, B., Hermann, T. 2014. Phosphorus levels in croplands of the

European Union with implications for P fertilizer use. European Journal of Agronomy, 55, 42-

52.

Tunney, H. 2002. Phoshorus needs of grassland soils and loss to water. 63-69. Agricultural effects on

ground and surface waters: research at the edge science and society (Steenvoorden, J.,

Claessen, F. and Willems, J.). International Association of Hydrological Sciences, Wallingford.

Valkama, E., Uusitalo, R., Ylivainio, K., Virkajarvi, P., Turtola, E. 2009. Phosphorus fertilization: A meta-

analysis of 80 years of research in Finland. Agriculture Ecosystems & Environment, 130, 75-

85.

van der Zee, S.E.A.T.M., van Riemsdijk, W.H., de Haan, F.A.M. 1990a. Het protokol fosfaatverzadigde

gronden. Deel I: Toelichting. Vakgroep Bodemkunde en Plantevoeding, Landbouwuniversiteit

Wageningen, Wageningen.

van der Zee, S.E.A.T.M., van Riemsdijk, W.H., de Haan, F.A.M. 1990b. Het protokol fosfaatverzadigde

gronden. Deel II: Technische uitwerking. Vakgroep Bodemkunde en Plantevoeding,

Landbouwuniversiteit Wageningen, Wageningen.

Van Meirvenne, M., Tariku, M., Salomez, J. 2007. Afbakening van de fosfaatverzadigde gebieden in

Vlaanderen op basis van een kritische fosfaatverzadigingsgraad van 35% - deel 1a:

afbakening.

Willems, W.J., Schröder, J.J. 2013. Ex ante evaluatie mestbeleid 2013. Bijlage notitie 2:

Plaatsingsruimte fosfaat uit meststoffen in 2016 en daarna. Plant Research International

Wageningen UR, Wageningen.

Ylivainio, K., Sarvi, M., Lemola, R., Uusitalo, R., Turtola, E. 2014. Regional P stocks in soil and in animal

manure as compared to P requirement of plants in Finland. MTT, Jukioinen.

PDF to HTML - Convert PDF files to HTML files

Appendix 1: Questionnaire for COST action 869

Question 1: Legislation on P application standards

Every country has its own advisory system to farmers, often based on the P status of the soil or on

direct P response of crops. This advice is voluntary. The question we are interested in: are these P

application rates also regulated in your national legislation (“by law”), e.g. via a maximum set for

annual P application rates? And if so, is the P status of the soil taken into account?

Question 2: Other regulations implemented?

Furthermore, are there any other types of official regulations implemented in legislation in your

country specifically to reduce P losses from agricultural land?

Question 3: Future expectations

Can such legislation be expected in the near future (or are there any developments in this area in

your government) regarding this subject, e.g. based on the discussions regarding the implementation

of the WFD?

PDF to HTML - Convert PDF files to HTML files

Appendix 2: Questions for update of phosphorus

legislation (2013-2014)



Is the use of phosphorus regulated in the national legislation related to the European Nitrate

Directive? What is the name of, and reference to, the legislation?

In which years is the legislation applicable? When is new legislation expected?

Are there standard application rates for phosphorus use on agricultural fields?

If no: is there an alternative (mandatory balance, tax on use,…)?

If yes:



What are the maximum application rates? Are these expressed in kg

/ha/y? Will these application rates change in the near future?



Is there a ‘philosophy’ or scientific basis for the maximum application rates

(e.g. standard = average crop P export, or is the standard related to the

maximum allowable P loss from an agricultural field,…)



Do the standard application rates take both manure and fertilisers into

account?



Can the farmer choose whether he/she uses manure or fertiliser?



Is there only one standard application rate or are the standards

differentiated? If differentiation: to crop, to soil P or to something else?



Are the standard application rates flat or are there exceptions? For example,

is there an exception for very intensive farms with crops that export more

phosphorus from the soil?



Is the standard application rate larger if two crops are grown in one year?



Can part of the standard application rate be transferred to the next year? If

so, what are the conditions?



Are there adapted standard rates for



soils that are sensitive to P loss? If yes: what are these rates? How

are these soils defined?



vulnerable areas? If yes: what are these rates? How are these areas

defined?



permanently covered soils



other kind of soils?



Certain types of manure, organic materials, etc. (e.g. compost in

Flanders)?

Are there subsidies for farmers that voluntary apply limited amounts of phosphorus? If yes:

what are the conditions?



PDF to HTML - Convert PDF files to HTML files

Appendix 3: Fertilisation prohibition periods

Prohibition periods of nutrient applications in European countries and regions (Adapted from

Hofman et al., 2013)

Country or region

Belgium

- Flanders

General prohibition period

1 Sept. - 15 Feb.

On heavy clay soils

15 Oct. - 15 Feb.

Champost and FYM

15 Nov. - 15 Jan.

Mineral N

Grassland: 15 Sept. - 31 Jan.

Other crops: 15 Oct. - 15 Feb.

Organic N

Grassland: 15 Sept. - 31 Jan

Other crops: 1 July - 15 Feb.

Exception: Catch crop or winter crop (limited till 80 kg N/ha): 15 Sept. –

15 Feb.

Denmark

Mineral N, solid manure and silage effluent

15 Nov. – 1 Feb.

No solid manure after harvest unless before winter crops

Silage effluent (unless it is on areas without green cover or if no crops

the following winter): harvest – 1 Nov.

Liquid manures, degassed organic mass

Harvest (at the latest 1 Oct.) – 1 Feb.

Grass seed: 15 Oct. – 1 Feb.

Established winter persistent feed grass areas, areas where winter rape

seeds are to be cultivated the following period, catch crops and yellow

mustard: 1 Oct. – 1 Feb.

Specific weather conditions: 15 Oct. – 1 Feb.

Perennial crops (no harvest): 1 Sep – 1 March

Mineral fertilisers:

Grassland

1 Oct. - 31 Jan.

Crops sown in autumn or at the end of the summer: 1 Sept. - 31 Jan.

Crops sown in spring: 1 July - 15 Feb.

Liquid manure, poultry manure:

Grassland: 15 Nov. - 15 Jan.

Crops sown in autumn or at the end of the summer: 1 Oct. - 31 Jan.

Crops sown in spring: 1 July - 31 Jan.

Crops sown in spring, preceded by green manure: from 1 July until 15

days before sowing green manure, and from 20 days before destruction

or harvest of green manure until 31 Jan.

Wallonia

France - Brittany

PDF to HTML - Convert PDF files to HTML files

Solid manure:

Grassland: 15 Dec. - 15 Jan.

Crops sown in autumn or at the end of the summer: 15 Nov. - 15 Jan.

Crops sown in spring: 1 July - 31 Aug. and 15 Nov. - 15 Jan.

Crops sown in spring, preceded by green manure: from 20 days before

destruction or harvest of green manure until 15 Jan.

England

Mineral fertilisers

Grassland: 15 Sept. - 15 Jan.

Other crops: 1 Sept. - 15 Jan.

Liquid manure

Grassland: 1 Sept. - 31 Dec. on shallow or sandy soils,

15 Oct. - 31 Jan. on other soils

Other crops: 1 Aug. - 31 Dec. on shallow or sandy soils,

1 Oct. - 28 Feb. on other soils

Solid manure

No prohibition period

Germany

Grassland: 15 Nov. - 31 Jan.

Other crops: 1 Nov. - 31 Jan.

After harvest of the main crop, no N fertilisation except when there is a

catch crop or a winter crop or straw will be incorporated (maximum 80

kg total N/ha or 40 kg NH

N/ha)

FYM all year round

Italy

Piemonte

Mineral fertilisers

15 Nov. - 15 Feb.

Liquid manure

Grassland + winter crops: 15 Nov - 15 Feb.

Other crops: 1 Nov. - 28 Feb.

Solid manure

Grassland: 15 Dec. - 15 Jan.

Other crops: 15 Nov. - 15 Feb.

The Netherlands

Mineral fertilisers

16 Sept. – 31 Jan.

Liquid manure

1 Sept. - 15 Feb.

Solid manure

1 Sept. - 31 Jan.

Arable land on clay and peat: no restrictions

PDF to HTML - Convert PDF files to HTML files

Poland

Mineral N fertilisers

Grassland: 15 Aug. - 1 March

Arable land: 15 Nov. – 1 March

Liquid manure and urea

Grassland: 15 Nov. – 1 March

Arable land: 15 Nov. – 1 March

Solid manure

Grassland: 30 Nov. – 1 March

Arable land: 15 Nov. – 1 March

Spain

Andalusia

Not in fallow period unless cover crop is present. Not before 15 days

before planting or sowing.

Perennial crops: from 1 Nov. - 29 Feb.

In one region, between 15 Dec. and 15 Feb.

- Murcia

Switzerland

Champost = composted substrate from mushroom production; FYM = farm yard manure

PDF to HTML - Convert PDF files to HTML files

Fien Amery

Institute for Agricultural and Fisheries Research (ILVO)

Plant Sciences Unit - Crop Husbandry and Environment

Burg. van Gansberghelaan 109

9820 Merelbeke (Belgium)

Tel +32 (0)9 272 27 08

Fax +32 (0)9 272 27 01

[email protected]

www.ilvo.vlaanderen.be

PDF to HTML - Convert PDF files to HTML files

Fien Amery

Institute for Agricultural and Fisheries Research (ILVO)

Plant Sciences Unit - Crop Husbandry and Environment

Burg. van Gansberghelaan 109

9820 Merelbeke (Belgium)

Tel +32 (0)9 272 27 08

Fax +32 (0)9 272 27 01

[email protected]
